FPAB 1603 6440
FPAB 1603 6440


Fixed castor 160 mm - 200 mm, 250 kg

Technical data

Diameter 160 mm
Wheel width 50 mm
Hub length 62 mm
Height 195 mm
Top plate dimensions 140 x 110 mm
Top plate hole diameter 10.5 mm
Dist. between holes 105 x 75,80 mm
Load capacity 250 kg
Weight 2.2 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Rigid fork of zinc-coated sheet steel
FPAU 1603 6440
FPAU 1603 6440


Fixed castor 160 mm - 200 mm, 250 kg

Technical data

Diameter 160 mm
Wheel width 50 mm
Hub length 62 mm
Height 195 mm
Top plate dimensions 140 x 110 mm
Top plate hole diameter 10.5 mm
Dist. between holes 105 x 75,80 mm
Load capacity 250 kg
Weight 2 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Rigid fork of zinc-coated sheet steel
FPCO 1001 5000
FPCO 1001 5000


Fixed castor 100 mm - 125 mm, 150 kg

Technical data

Diameter 100 mm
Wheel width 35 mm
Hub length 42 mm
Height 128 mm
Wheel axle diameter 8 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 128 mm
Load capacity 150 kg
Weight 0.7 kg
Reach compliant Rohs compliant

Wheel

  • Composite wheel polypropylene with red noise-reducing
  • thermoplastic rubber infill with one deep groove ball bearing

Technical description

  • Rigid fork of zinc-coated sheet steel
FPPB 0801 5000
FPPB 0801 5000


Fixed castor 80 mm - 125 mm, 150 kg

Technical data

Diameter 80 mm
Wheel width 35 mm
Hub length 42 mm
Height 105 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Load capacity 150 kg
Weight 0.7 kg
Reach compliant Rohs compliant

Wheel

  • Polyamide wheel with blue rubber tyre
  • (Shore A 70) with one deep groove ball bearing

Technical description

  • Rigid fork of zinc-coated sheet steel
FPPB 1001 2000
FPPB 1001 2000


Fixed castor 100 mm, 150 kg

Technical data

Diameter 100 mm
Wheel width 35 mm
Hub length 40 mm
Height 128 mm
Wheel axle diameter 12 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 128 mm
Load capacity 150 kg
Weight 0.5 kg
Reach compliant Rohs compliant

Wheel

  • Polyamide wheel with blue rubber tyre
  • (Shore A 70) with roller bearing

Technical description

  • Rigid fork of zinc-coated sheet steel
FPPB 1001 2001
FPPB 1001 2001


Fixed castor 100 mm - 200 mm, 150 kg - 220 kg

Technical data

Diameter 100 mm
Wheel width 35 mm
Hub length 40 mm
Height 128 mm
Wheel axle diameter 12 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 128 mm
Load capacity 150 kg
Weight 0.6 kg
Reach compliant Rohs compliant

Wheel

  • Polyamide wheel with blue rubber tyre
  • (Shore A 70) with roller bearing

Technical description

  • Rigid fork of zinc-coated sheet steel
FPPB 1251 2000
FPPB 1251 2000


Fixed castor 125 mm - 200 mm, 150 kg - 220 kg

Technical data

Diameter 125 mm
Wheel width 35 mm
Hub length 45 mm
Height 156 mm
Wheel axle diameter 15 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 138 mm
Load capacity 150 kg
Weight 1 kg
Reach compliant Rohs compliant

Wheel

  • Polyamide wheel with blue rubber tyre
  • (Shore A 70) with roller bearing

Technical description

  • Rigid fork of zinc-coated sheet steel
FPPC 0801 7000
FPPC 0801 7000


Fixed castor 80 mm - 125 mm, 80 kg - 150 kg

Technical data

Diameter 80 mm
Wheel width 32 mm
Hub length 42 mm
Height 105 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Load capacity 80 kg
Weight 0.38 kg
Reach compliant Rohs compliant

Wheel

  • Dark grey Polypropyleene wheel with grey antistatic rubber tyre
  • (Performa, Shore A 65 - 70) with one stainless steel deep groove ball bearing

Technical description

  • Rigid fork of zinc-coated sheet steel
FPPE 1251 5000 (Ecoforma)
FPPE 1251 5000


Fixed castor 125 mm - 200 mm, 110 kg - 225 kg

Technical data

Diameter 125 mm
Wheel width 32 mm
Hub length 45 mm
Height 156 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9.6 mm
Dist. between holes 80 x 60 mm
Load capacity 110 kg
Weight 0.8 kg
Reach compliant Rohs compliant

Wheel

  • Polypropylene wheel centre with grey thermoplastic rubber tyre (Ecoforma - Shore A 65-70) and a sealed precision ball bearing

Technical description

  • Fixed fork of deep drawn zinc-coated steel

Areas of application

  • Transportation & Logistics
  • Material Handling
  • Packaging
  • Automotive
  • Food & Beverage (Catering), etc.
FPPE 1603 5000-NL
FPPE 1603 5000-NL


Fixed castor 80 mm - 200 mm, 120 kg - 225 kg

Technical data

Diameter 160 mm
Wheel width 40 mm
Hub length 64 mm
Height 195 mm
Offset 53 mm
Top plate dimensions 135 x 110 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Load capacity 200 kg
Reach compliant Rohs compliant

Wheel

  • Dark grey Polypropyleene wheel with grey rubber tyre
  • (Ecoforma, Shore A 65 - 70)

Technical description

  • Rigid fork of zinc-coated sheet steel
