Furniture Castors

Moveable small and large furniture ensures flexibility and creates room for change. With furniture castors from Colson , sofabeds, audio furniture, tables, cupboards and many other furnishings can be ideally positioned, but still remain mobile.

No matter what the floor requirements, Colson has the right solution on hand, and that is in classic Colson quality, with all the characteristics to be expected of a furniture castor.

Swivel castor 125 mm - 200 mm, 490 kg - 500 kg

Technical data

Diameter 200 mm
Wheel width 50 mm
Hub length 64 mm
Height 235 mm
Offset 60 mm
Wheel axle diameter 20 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 500 kg
Weight 3.5 kg
Reach compliant Rohs compliant

Wheel

  • Glass fibre reinforced polyamide wheel

Technical description

  • Swivel fork of deep drawn stainless steel with wheel brake.
  • Swivelhead with sealed precision ball bearing, grease nippel
  • and O-ring seal. In case of extreme conditions
  • (like frequent jet cleaning) maintenance by relubrication
  • is necessary
