Furniture Castors
Moveable small and large furniture ensures flexibility and creates room for change. With furniture castors from Colson , sofabeds, audio furniture, tables, cupboards and many other furnishings can be ideally positioned, but still remain mobile.
No matter what the floor requirements, Colson has the right solution on hand, and that is in classic Colson quality, with all the characteristics to be expected of a furniture castor.
JXRN 2003 6443/B
Swivel castor 125 mm - 200 mm, 490 kg - 500 kg
Technical data
| Diameter | 200 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Height | 235 mm |
| Offset | 60 mm |
| Wheel axle diameter | 20 mm |
| Top plate dimensions | 135 x 112 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 75,80 mm |
| Brake swivel radius | 145 mm |
| Load capacity | 500 kg |
| Weight | 3.5 kg |
Wheel
- Glass fibre reinforced polyamide wheel
Technical description
- Swivel fork of deep drawn stainless steel with wheel brake.
- Swivelhead with sealed precision ball bearing, grease nippel
- and O-ring seal. In case of extreme conditions
- (like frequent jet cleaning) maintenance by relubrication
- is necessary
