Stainless Steel Castors
In the age of high technology the latest hygiene regulations shape the climate in laboratories for biotechnology, medicine and food research. Cleanliness is an essential part of quality management. Stainless steel castors from RHOMBUS are dazzling with their outstanding properties for this kind of environment. Produced from high-quality pure steel and precisely manufactured, they bring sterilising and instrument cabinets and other mobile units safe and clean to their destination.
JBPN 070-CC1/ARTLP22
Swivel castor 58 mm - 70 mm, 250 kg
Technical data
| Diameter | 70 mm |
| Wheel width | 35 mm |
| Hub length | 45 mm |
| Height | 102 mm |
| Offset | 25 mm |
| Top plate dimensions | 111 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 85.9 x 60.5 mm |
| Brake swivel radius | 60 mm |
| Load capacity | 250 kg |
| Weight | 1 kg |
Wheel
- Engineered Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork with sealed deep groove ball bearing operating temperatures from -30°C to + 80°C
