FFCN 1003 6000
Fixed castor 100 mm - 250 mm, 800 kg - 1240 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Height | 152 mm |
| Top plate dimensions | 150 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 800 kg |
| Weight | 1.9 kg |
Wheel
- Cast iron wheel with two deep groove ball bearings
Technical description
- Heavy duty welded steel rigid fork
FFCV 1003 6000
Fixed castor 100 mm - 300 mm, 340 kg - 1500 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 38 mm |
| Hub length | 57 mm |
| Height | 152 mm |
| Top plate dimensions | 150 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 340 kg |
| Weight | 3.5 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
Technical description
- Heavy duty welded steel rigid fork
FFPN 1003 6000
Fixed castor 100 mm - 250 mm, 1000 kg - 1500 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 50 mm |
| Hub length | 62 mm |
| Height | 152 mm |
| Offset | 52 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 150 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 1000 kg |
| Weight | 1.8 kg |
Wheel
- Polyamide wheel with two deep groove ball bearings
Technical description
- Heavy duty welded steel rigid fork
FIX 2-P1
Technical data
| Weight | 0.4 kg |
FLFL 0801 1000 (Bäckerei-Bakery-Bakkerij)
Fixed castor 80 mm - 160 mm, 150 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 150 kg |
| Weight | 1 kg |
Wheel
- Phenolic wheel with a plain bearing operating temperatures from -40°C to +250°C
FLFL 1001 6152
Fixed castor 100 mm, 150 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Hub length | 45 mm |
| Height | 128 mm |
| Wheel axle diameter | 8 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 150 kg |
| Weight | 1.2 kg |
Wheel
- Phenolic wheel for light Industrial use two ball bearings with labyrinth seals and bushing operating temperatures from -40°C to +250°C
FLHN 0701 6152
Fixed castor 70 mm - 100 mm, 150 kg
Technical data
| Diameter | 70 mm |
| Height | 105 mm |
| Top plate dimensions | 105x85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80x60 mm |
| Brake swivel radius | 12 mm |
| Load capacity | 150 kg |
Wheel
- Varmo a high wear resistant synthetic material High resistance to moisture and water Sound reducing properties Temperature resistance -40°C to + 300 °C with two deep groove ball bearings
Technical description
- Rigid fork of zinc-coated sheet steel
FLPL 3.00-4
Fixed castor 260 mm, 170 kg
Technical data
| Diameter | 260 mm |
| Wheel width | 85 mm |
| Hub length | 75 mm |
| Height | 307 mm |
| Top plate dimensions | 175 x 175 mm |
| Top plate hole diameter | 14.5 mm |
| Dist. between holes | 140 x 140 mm |
| Load capacity | 170 kg |
| Weight | 3.75 kg |
Wheel
- Pneumatic wheel with a red plastic core
- black tyre
FLPT 1001 1000
Fixed castor 100 mm, 75 kg
Technical data
| Diameter | 100 mm |
| Height | 128 mm |
| Top plate dimensions | 105x85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80x60 mm |
| Brake swivel radius | 12 mm |
| Load capacity | 75 kg |
Wheel
- Plastic wheel with high temperature black rubber tyre
- (Shore A 62). Temperature resistance -40°C to + 300 °C
Technical description
- Rigid fork of zinc-coated sheet steel
FLSU 3.00-4
Fixed castor 260 mm, 70 kg
Technical data
| Diameter | 260 mm |
| Wheel width | 85 mm |
| Height | 307 mm |
| Offset | 55 mm |
| Top plate dimensions | 200x160 mm |
| Top plate hole diameter | 14x26 mm |
| Dist. between holes | 150x115 mm |
| Load capacity | 70 kg |
Wheel
- Puncture proof yellow polyurethane wheel with grey metal rim
