FPRG 0801 5000
Fixed castor 80 mm - 125 mm, 150 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 8 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 150 kg |
| Weight | 0.7 kg |
Wheel
- Glass fibre reinforced polyamide wheel with grey rubber tyre
- (Shore A 65) with one deep groove ball bearing
Technical description
- Rigid fork of zinc-coated sheet steel
FPSG 0801 2000
Fixed castor 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 0.5 kg |
Wheel
- Pressed sheetsteel wheel with grey rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Rigid fork of zinc-coated sheet steel
FPSG 0801 2001
Fixed castor 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 0.6 kg |
Wheel
- Pressed sheetsteel wheel with grey rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Rigid fork of zinc-coated sheet steel
FPSM 0801 2000
Fixed castor 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 0.5 kg |
Wheel
- Pressed sheetsteel wheel with black rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Rigid fork of zinc-coated sheet steel
FPSM 0801 2001
Fixed castor 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 0.6 kg |
Wheel
- Pressed sheetsteel wheel with black rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Rigid fork of zinc-coated sheet steel
FRCN 1003 2000
Fixed castor 100 mm - 200 mm, 450 kg - 600 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 38 mm |
| Hub length | 48 mm |
| Height | 140 mm |
| Offset | 33 mm |
| Wheel axle diameter | 15 mm |
| Top plate dimensions | 135 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 450 kg |
| Weight | 2.3 kg |
Wheel
- Cast iron wheel with two deep groove ball bearings
FRCU 1003 2000
Fixed castor 100 mm - 200 mm, 295 kg - 600 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 45 mm |
| Hub length | 48 mm |
| Height | 140 mm |
| Offset | 33 mm |
| Wheel axle diameter | 15 mm |
| Top plate dimensions | 135 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 295 kg |
| Weight | 2.2 kg |
Wheel
- Cast iron wheel with bonded-on polyurethane tyre (Shore A 92) with two taper roller bearings
FSAB 1002 6150
Fixed castor 100 mm - 250 mm, 180 kg - 550 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Hub length | 45 mm |
| Height | 130 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 180 kg |
| Weight | 1 kg |
Wheel
- Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Rigid fork of zinc-coated sheet steel
FSAN 1002 6150 (High Temperature)
Fixed castor 100 mm, 240 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Height | 130 mm |
| Top plate dimensions | 105x85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80x60 mm |
| Load capacity | 240 kg |
Wheel
- cast aluminium body
- operating temperature up to +300°C
- double ball
- bearing
Technical description
- pressed components made of carbon steel protected with an additional electro-galvanized zinc coating
FSAT 1001 6150
Fixed castor 100 mm, 80 kg
Technical data
| Diameter | 100 mm |
| Height | 130 mm |
| Top plate dimensions | 105x85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80x60 mm |
| Brake swivel radius | 12 mm |
| Load capacity | 80 kg |
Wheel
- High temperature rubber tyre 80° Shore A aluminium wheel centre with 2 ball bearings operating temperature from -40°C to +250°C not resistant to vegetable oils
Technical description
- Rigid fork of zinc-coated sheet steel
