Wheels & Accessories
The composition of the tyre and the various types of wheel rims or hubs as well as various wheel bearings give the wheel many different properties. Because of this wheels have differing load capacities, resistance to rolling and operational qualities.
JBPN 058-CC1/A-R
Swivel castor 58 mm - 70 mm, 250 kg
Technical data
Diameter | 58 mm |
Wheel width | 35 mm |
Hub length | 45 mm |
Height | 96 mm |
Offset | 25 mm |
Top plate dimensions | 111 x 80 mm |
Top plate hole diameter | 9 mm |
Dist. between holes | 85.9 x 60.5 mm |
Brake swivel radius | 54 mm |
Load capacity | 250 kg |
Weight | 0.81 kg |
Wheel
- Engineered Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork with sealed deep groove ball bearing operating temperatures from -30°C to + 80°C
JBPN 058-CC1/A-RT12,7
Swivel castor 58 mm - 70 mm, 250 kg
Technical data
Diameter | 58 mm |
Wheel width | 35 mm |
Hub length | 45 mm |
Height | 96 mm |
Offset | 25 mm |
Top plate dimensions | 111 x 80 mm |
Top plate hole diameter | 9 mm |
Dist. between holes | 85.9 x 60.5 mm |
Brake swivel radius | 54 mm |
Load capacity | 250 kg |
Weight | 0.97 kg |
Wheel
- Engineered Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork with sealed deep groove ball bearing operating temperatures from -30°C to + 80°C
