BXNY 0802 7100
Swivel castor 80 mm - 200 mm, 200 kg - 600 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 111 mm |
| Offset | 40 mm |
| Wheel axle diameter | 8 mm |
| Top plate dimensions | 105x86 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80/77x60 mm |
| Load capacity | 200 kg |
Wheel
- Polyamide wheel with one sealed stainless steel
- deep groove ball bearing
Technical description
- Heavy duty swivel fork of deep drawn stainless steel, swivel bearing with double ball race and sealring
- with a total lock brake
BXNY 1507 6440
Swivel castor 150 mm - 200 mm, 400 kg - 600 kg
Technical data
| Diameter | 150 mm |
| Wheel width | 50 mm |
| Hub length | 60 mm |
| Height | 190 mm |
| Offset | 53 mm |
| Wheel axle diameter | 20 mm |
| Bolt hole diameter | 16.3 mm |
| Load capacity | 400 kg |
Wheel
- Polyamide wheel with two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPC 0801 7100
Swivel castor with total brake mounted behind 80 mm - 200 mm, 80 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 80 kg |
| Weight | 0.69 kg |
Wheel
- Dark grey Polypropyleene wheel with grey antistatic rubber tyre
- (Performa, Shore A 65 - 70) with one stainless steel deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPC 0805 7000
Swivel castor with total brake mounted behind 80 mm - 125 mm, 80 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 80 kg |
| Weight | 0.76 kg |
Wheel
- Dark grey Polypropyleene wheel with grey antistatic rubber tyre
- (Performa, Shore A 65 - 70) with one stainless steel deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPC 1607 6443
Swivel castor with total brake mounted behind 160 mm - 200 mm, 300 kg - 250 kg
Technical data
| Diameter | 160 mm |
| Hub length | 64 mm |
| Height | 195 mm |
| Offset | 53 mm |
| Wheel axle diameter | 20 mm |
| Threaded stem size | 50 mm |
| Load capacity | 300 kg |
| Weight | 2 kg |
Wheel
- Dark grey Polypropyleene wheel with grey antistatic rubber tyre
- (Performa, Shore A 65 - 70) with two steel deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPF 0801 7100
Swivel castor with total brake mounted behind 80 mm - 200 mm, 120 kg - 300 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 120 kg |
| Weight | 0.7 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPF 0805 7000
Swivel castor with total brake mounted behind 80 mm - 125 mm, 120 kg - 180 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 120 kg |
| Weight | 0.77 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPF 1607 6443
Swivel castor with total brake mounted behind 160 mm - 200 mm, 500 kg
Technical data
| Diameter | 160 mm |
| Hub length | 64 mm |
| Height | 195 mm |
| Offset | 53 mm |
| Wheel axle diameter | 20 mm |
| Threaded stem size | 50 mm |
| Load capacity | 500 kg |
| Weight | 2 kg |
Wheel
- Dark grey Polypropyleene wheel with grey elastic Performa tyre
- (65° - 70° Shore A) with two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPG 0801 1100
Swivel castor with total brake mounted behind 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPG 0805 1000
Swivel castor with total brake mounted behind 80 mm - 125 mm, 50 kg - 100 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.5 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
