441i 08R160c ZPK
Swivel castor with total brake mounted in front 160 mm - 200 mm, 135 kg - 205 kg
Technical data
| Diameter | 160 mm |
| Tread width | 28 mm |
| Height | 197 mm |
| Offset | 48 mm |
| Top plate dimensions | 138x109 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105x75/80 mm |
| Load capacity | 135 kg |
| Weight | 2845 g |
Wheel
- solid rubber tyre black (Shore A 80)
- sheet steel metal rim zinc passivated
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
477a 0SR100p ZPK
Fixed castor 100 mm - 200 mm, 500 kg - 600 kg
Technical data
| Diameter | 100 mm |
| Tread width | 45 mm |
| Height | 148 mm |
| Top plate dimensions | 138x109 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105x75/80 mm |
| Load capacity | 500 kg |
| Weight | 1269 g |
Wheel
- polyamide white
- roller bearing
Technical description
- heavy sheet steel housing zinc passivated
- zinc passivated
Areas of application
- picking carts
- assembly dolly
- transport containers
- containers
- heavy transport equipment
- waste disposal containers
477a 18K100v ZPK
Fixed castor 100 mm - 200 mm, 275 kg - 600 kg
Technical data
| Diameter | 100 mm |
| Tread width | 40 mm |
| Height | 148 mm |
| Top plate dimensions | 138x109 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105x75/80 mm |
| Load capacity | 275 kg |
Wheel
- Polyurethane tyre red-orange (Shore A 95)
- bonded on cast wheel centre
- precision ball bearing
Technical description
- heavy sheet steel housing zinc passivated
- zinc passivated
Areas of application
- picking carts
- assembly dolly
- transport containers
- containers
- heavy transport equipment
- waste disposal containers
478a 0SR100p ZPK
Swivel castor 100 mm - 200 mm, 500 kg - 600 kg
Technical data
| Diameter | 100 mm |
| Tread width | 45 mm |
| Height | 148 mm |
| Offset | 48 mm |
| Top plate dimensions | 138x109 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105x75/80 mm |
| Load capacity | 500 kg |
| Weight | 2433 g |
Wheel
- polyamide white
- roller bearing
Technical description
- heavy sheet steel housing zinc passivated
- special swivel head with double ball race
- triple-bolted to fork head
- maintenance-free permanently grease filled in fork head, zinc passivated
- protected against dust and water by sealed swivel head
- screw-on directional lock <<ASL 478>> is available optionally (can be ordered separately as accessory)
Areas of application
- picking carts
- assembly dolly
- transport containers
- containers
- heavy transport equipment
- waste disposal containers
478a 18K125v ZPK
Swivel castor 100 mm - 200 mm, 275 kg - 600 kg
Technical data
| Diameter | 125 mm |
| Tread width | 40 mm |
| Height | 178 mm |
| Offset | 48 mm |
| Top plate dimensions | 138x109 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105x75/80 mm |
| Load capacity | 350 kg |
Wheel
- Polyurethane tyre red-orange (Shore A 95)
- bonded on cast wheel centre
- precision ball bearing
Technical description
- heavy sheet steel housing zinc passivated
- special swivel head with double ball race
- triple-bolted to fork head
- maintenance-free permanently grease filled in fork head, zinc passivated
- protected against dust and water by sealed swivel head
- screw-on directional lock <<ASL 478>> is available optionally (can be ordered separately as accessory)
Areas of application
- assembly dolly
- containers
- heavy transport equipment
- picking carts
- transport containers
- transport trolleys
- waste disposal containers
478i 0SR125p ZPK
Swivel castor with total brake mounted in front 125 mm - 200 mm, 600 kg
Technical data
| Diameter | 125 mm |
| Tread width | 45 mm |
| Height | 178 mm |
| Offset | 48 mm |
| Top plate dimensions | 138x109 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105x75/80 mm |
| Load capacity | 600 kg |
| Weight | 2942 g |
Wheel
- polyamide white
- roller bearing
Technical description
- heavy sheet steel housing zinc passivated
- special swivel head with double ball race
- triple-bolted to fork head
- maintenance-free permanently grease filled in fork head, zinc passivated
- protected against dust and water by sealed swivel head
Areas of application
- picking carts
- assembly dolly
- transport containers
- containers
- heavy transport equipment
- waste disposal containers
478i 18K125v ZPK
Swivel castor with total brake mounted in front 125 mm - 200 mm, 350 kg - 600 kg
Technical data
| Diameter | 125 mm |
| Tread width | 40 mm |
| Height | 178 mm |
| Offset | 48 mm |
| Top plate dimensions | 138x109 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105x75/80 mm |
| Load capacity | 350 kg |
Wheel
- Polyurethane tyre red-orange (Shore A 95)
- bonded on cast wheel centre
- precision ball bearing
Technical description
- heavy sheet steel housing zinc passivated
- special swivel head with double ball race
- triple-bolted to fork head
- maintenance-free permanently grease filled in fork head, zinc passivated
- protected against dust and water by sealed swivel head
Areas of application
- picking carts
- assembly dolly
- transport containers
- containers
- heavy transport equipment
- waste disposal containers
504a 0SK085p ZPS
On request
Fixed castor 85 mm, 1200 kg
Technical data
| Diameter | 85 mm |
| Tread width | 85 mm |
| Height | 125 mm |
| Top plate dimensions | 190x170 mm |
| Top plate hole diameter | 16,5 mm |
| Dist. between holes | 150x135 mm |
| Load capacity | 1200 kg |
Technical description
- heavy steel welded construction
- zinc passivated
Areas of application
- containers
- fork lift trucks
- lifting carts
- lifting tables
- lifting platforms
- machine constructions
- heavy transport equipment
504a 18K085v ZPS
On request
Fixed castor 85 mm, 700 kg
Technical data
| Diameter | 85 mm |
| Tread width | 85 mm |
| Height | 125 mm |
| Top plate dimensions | 190x170 mm |
| Top plate hole diameter | 16,5 mm |
| Dist. between holes | 150x135 mm |
| Load capacity | 700 kg |
Wheel
- Polyurethane tyre red-orange (Shore A 95)
- bonded on cast wheel centre
- precision ball bearing
Technical description
- heavy steel welded construction
- zinc passivated
Areas of application
- containers
- fork lift trucks
- lifting carts
- lifting tables
- lifting platforms
- machine constructions
- heavy transport equipment
505a 0SK085p ZPS
On request
Swivel castor 85 mm, 1200 kg
Technical data
| Diameter | 85 mm |
| Tread width | 85 mm |
| Height | 125 mm |
| Offset | 57 mm |
| Top plate dimensions | 190x170 mm |
| Top plate hole diameter | 16,5 mm |
| Dist. between holes | 150x135 mm |
| Load capacity | 1200 kg |
Technical description
- heavy steel welded construction with special turntable
- zinc passivated
- pressed ball track above, with tapered roller bearing below
- grease filling and grease nipple in fork head
Areas of application
- containers
- fork lift trucks
- lifting carts
- lifting tables
- lifting platforms
- machine constructions
- heavy transport equipment
