441a 08R080c ZLD
Swivel castor 80 mm - 125 mm, 50 kg - 100 kg
Technical data
| Diameter | 80 mm |
| Tread width | 20 mm |
| Height | 105,5 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 50 kg |
Wheel
- solid rubber tyre black (Shore A 80)
- sheet steel metal rim zinc passivated
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
441a 08R080c ZLD-5
On request
Swivel castor 80 mm - 200 mm, 70 kg - 230 kg
Technical data
| Diameter | 80 mm |
| Tread width | 22 mm |
| Height | 110 mm |
| Offset | 35 mm |
| Bolt hole diameter | 12,5 mm |
| Load capacity | 70 kg |
Wheel
- solid rubber tyre black (Shore A 80)
- sheet steel metal rim zinc passivated
- roller bearing
Technical description
- Stable sheet steel design and proven technology
- Easy running double ball bearing for good manoeuvrability
- Sealing ring in swivel head
Areas of application
- magazine carts
- tool trolleys
- transport containers
- waste containers
- tool trolleys
441a 08R080c ZPH
Swivel castor 80 mm - 200 mm, 50 kg - 205 kg
Technical data
| Diameter | 80 mm |
| Tread width | 20 mm |
| Height | 107 mm |
| Offset | 34 mm |
| Top plate dimensions | 104x80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 72x52/80x60 mm |
| Load capacity | 50 kg |
| Weight | 693 g |
Wheel
- solid rubber tyre black (Shore A 80)
- sheet steel metal rim zinc passivated
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
441a 08R080c ZPH-5
On request
Swivel castor 80 mm - 200 mm, 70 kg - 230 kg
Technical data
| Diameter | 80 mm |
| Tread width | 22 mm |
| Height | 112 mm |
| Offset | 35 mm |
| Top plate dimensions | 100x80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80x60 mm |
| Load capacity | 70 kg |
Wheel
- solid rubber tyre black (Shore A 80)
- sheet steel metal rim zinc passivated
- roller bearing
Technical description
- Stable sheet steel design and proven technology
- Easy running double ball bearing for good manoeuvrability
- Sealing ring in swivel head
Areas of application
- magazine carts
- tool trolleys
- transport containers
- waste containers
- tool trolleys
441a 14R100d ZLD
On request
Swivel castor 100 mm - 125 mm, 140 kg
Technical data
| Diameter | 100 mm |
| Tread width | 26 mm |
| Height | 128 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 140 kg |
Wheel
- elastic solid rubber tyre blue (Shore A 70)
- vulcanised firmly on plastic wheel centre black
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
441a 14R100d ZPH
On request
Swivel castor 100 mm - 125 mm, 140 kg
Technical data
| Diameter | 100 mm |
| Tread width | 26 mm |
| Height | 128 mm |
| Offset | 34 mm |
| Top plate dimensions | 104x80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 72x52/80x60 mm |
| Load capacity | 140 kg |
| Weight | 737 g |
Wheel
- elastic solid rubber tyre blue (Shore A 70)
- vulcanised firmly on plastic wheel centre black
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
441h 00R065p ZLD
On request
Swivel castor with total brake mounted behind 65 mm - 125 mm, 100 kg - 125 kg
Technical data
| Diameter | 65 mm |
| Tread width | 33 mm |
| Height | 90,5 mm |
| Offset | 37,5 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
Wheel
- polyamide white
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
441h 00R065p ZPH
Swivel castor with total brake mounted behind 65 mm - 125 mm, 100 kg - 150 kg
Technical data
| Diameter | 65 mm |
| Tread width | 33 mm |
| Height | 92 mm |
| Offset | 37,5 mm |
| Top plate dimensions | 104x80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 72x52/80x60 mm |
| Load capacity | 100 kg |
Wheel
- polyamide white
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
441h 07R080c ZLD
Swivel castor with total brake mounted behind 80 mm - 125 mm, 50 kg - 100 kg
Technical data
| Diameter | 80 mm |
| Tread width | 20 mm |
| Height | 105,5 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 50 kg |
Wheel
- solid rubber tyre black (Shore A 80)
- plastic wheel centre
- roller bearing
Technical description
- stable sheet steel design and proven technology
- easy running double ball bearing for good manoeuvrability
- wide choice of wheels for different areas of application
Areas of application
- assembly dolly
- creeper dolly
- picking carts
- transport containers
- magazine carts
- tool trolleys
- waste disposal containers
441h 07R080c ZLD-5
On request
Swivel castor with total brake mounted behind 80 mm - 200 mm, 60 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Tread width | 22 mm |
| Height | 110.0 mm |
| Offset | 35 mm |
| Bolt hole diameter | 12,5 mm |
| Load capacity | 60 kg |
Wheel
- solid rubber tyre black (Shore A 80)
- plastic wheel centre
- roller bearing
Technical description
- Stable sheet steel design and proven technology
- Easy running double ball bearing for good manoeuvrability
- Sealing ring in swivel head
Areas of application
- magazine carts
- tool trolleys
- transport containers
- waste containers
- tool trolleys
