M28QZ-UF2K080 (390q 29K080v Z2351ZA)
On request
Swivel castor with central total brake 80 mm - 150 mm, 80 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 113 mm |
| Offset | 44 mm |
| Stem size | 28x100 (41°/52°) mm |
| Load capacity | 80 kg |
Wheel
- thermoplastic polyurethane tyre (TPU) iron grey RAL 7011 (Shore A 95)
- plastic wheel centre and thread guard silver grey RAL7001
- free of contact discoloration
- precision ball bearing
Technical description
- sheet steel metal housing
- zinc passivated
- double ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical & diagnostic equipment
- medical-technical equipment
- op beds
- op tables
M28QZ-UF2K080-AS (390q 29K080y Z2351ZA)
On request
Swivel castor with central total brake 80 mm - 150 mm, 80 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 113 mm |
| Offset | 44 mm |
| Stem size | 28x100 (41°/52°) mm |
| Load capacity | 80 kg |
Wheel
- thermoplastic polyurethane tyre (TPU) iron grey RAL 7011 (Shore A 95)
- electrically conductive, free of contact discoloration
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
Technical description
- sheet steel metal housing
- zinc passivated
- double ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical & diagnostic equipment
- medical-technical equipment
- op beds
- op tables
M29QZ-GF7B080 (390q 32C080b Z985NP)
On request
Swivel castor with central total brake 80 mm - 200 mm, 80 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 113 mm |
| Offset | 44 mm |
| Stem size | 32x50 (30°) mm |
| Load capacity | 80 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- zinc passivated
- double ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
M29QZ-RF2K080 (390q 29K080r Z985NP)
On request
Swivel castor with central total brake 80 mm - 200 mm, 80 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 113 mm |
| Offset | 44 mm |
| Stem size | 32x50 (30°) mm |
| Load capacity | 80 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- double ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
M29QZ-RF2K080-AS (390q 29K080a Z985NP)
On request
Swivel castor with central total brake 80 mm - 150 mm, 80 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 113 mm |
| Offset | 44 mm |
| Stem size | 32x50 (30°) mm |
| Load capacity | 80 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- electrically conductive
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- double ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical & diagnostic equipment
- medical-technical equipment
- op beds
- op tables
M29QZ-UF2K080-AS (390q 29K080y Z985NP)
On request
Swivel castor with central total brake 80 mm - 150 mm, 80 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Height | 113 mm |
| Offset | 44 mm |
| Stem size | 32x50 (30°) mm |
| Load capacity | 80 kg |
Wheel
- thermoplastic polyurethane tyre (TPU) iron grey RAL 7011 (Shore A 95)
- electrically conductive, free of contact discoloration
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
Technical description
- sheet steel metal housing
- zinc passivated
- double ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical & diagnostic equipment
- medical-technical equipment
- op beds
- op tables
M29QZ-UF2K100 (390q 29K100v Z985NP)
On request
Swivel castor with central total brake 80 mm - 150 mm, 80 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 133 mm |
| Offset | 42 mm |
| Stem size | 32x50 (30°) mm |
| Load capacity | 100 kg |
| Weight | 936 g |
Wheel
- thermoplastic polyurethane tyre (TPU) iron grey RAL 7011 (Shore A 95)
- plastic wheel centre and thread guard silver grey RAL7001
- free of contact discoloration
- precision ball bearing
Technical description
- sheet steel metal housing
- zinc passivated
- double ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical & diagnostic equipment
- medical-technical equipment
- op beds
- op tables
MNL
Transmission lever
Technical data
| Weight | 89 g |
Technical description
- Transmission lever long for central locking bed castors
NILF-44CAN-L12
Swivel castor with total brake mounted behind 100 mm - 125 mm, 150 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Hub length | 42 mm |
| Height | 128 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12 mm |
| Load capacity | 150 kg |
Wheel
- TPU tread conductive (Shore A 95)
- polyamide wheel body
- thread guard
- stainless steel ball bearing
Technical description
- stainless steel housing
- swivel bearing with double ball race
- ball bearings of stainless steel
- sealing ring
Areas of application
- Laundry carts
- bakery oven units
- catering equipment
- food industry
- food transport equipment
- industrial kitchen equipment
- laundry
- mobile shelves
- pharmaceutical industry
- serving trolleys
- waste disposal systems
NKMAF-31CAN-L11 (VIVAX EasyFit)
Swivel castor with wheel locking brake 75 mm, 70 kg
Technical data
| Diameter | 75 mm |
| Wheel width | 25 mm |
| Height | 105 mm |
| Bolt hole diameter | 11 mm |
| Load capacity | 70 kg |
