391q 29K100r Z2351
Swivel castor with central total brake 100 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
391q 29K100r Z985
Swivel castor with central total brake 100 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
391q 32C100b Z2351
Swivel castor with central total brake 100 mm - 200 mm, 80 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Load capacity | 80 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
391q 32C100b Z985
Swivel castor with central total brake 100 mm - 200 mm, 80 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Height | 139 mm |
| Offset | 42 mm |
| Load capacity | 80 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- zinc passivated
- presicion ball bearing in swivel head
- protected from dust and water ingress by plastic sealing ring
- integrated selection mechanism with total locking brake "q"
- and directional locking brake "r"
- selection mechanism continually greased
- device to permit adjustment of the braking effect
- (without removing the castor or wheel)
- also available with other wheel variants
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
394a 29G100r ELD
Swivel castor 100 mm - 125 mm, 100 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 131,5 mm |
| Offset | 42 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- stainless steel housing
- swivel bearing with double ball race
- ball bearings of stainless steel
- sealing ring
- also available with bolt hole LC (10,2 mm)
Areas of application
- industrial kitchen equipment
- bakery oven units
- catering equipment
- food processing industry
- food transport equipment
- laundry carts
- pharmaceutical industry
- serving trolleys
- waste disposal systems
394a 29G100r EPD
Swivel castor 100 mm - 125 mm, 100 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 138 mm |
| Offset | 42 mm |
| Top plate dimensions | 77x67 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 61x51/57x48 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- stainless steel housing
- swivel bearing with double ball race
- ball bearings of stainless steel
- sealing ring
- also available with bolt hole LC (10,2 mm)
Areas of application
- industrial kitchen equipment
- bakery oven units
- catering equipment
- food processing industry
- food transport equipment
- laundry carts
- pharmaceutical industry
- serving trolleys
- waste disposal systems
394h 29G100r ELD
Swivel castor with total brake mounted behind 100 mm - 125 mm, 100 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 131,5 mm |
| Offset | 42 mm |
| Bolt hole diameter | 12,2 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- stainless steel housing
- swivel bearing with double ball race
- ball bearings of stainless steel
- sealing ring
- also available with bolt hole LC (10,2 mm)
Areas of application
- industrial kitchen equipment
- bakery oven units
- catering equipment
- food processing industry
- food transport equipment
- laundry carts
- pharmaceutical industry
- serving trolleys
- waste disposal systems
394h 29G100r EPD
Swivel castor with total brake mounted behind 100 mm - 125 mm, 100 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 138 mm |
| Offset | 42 mm |
| Top plate dimensions | 77x67 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 61x51/57x48 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- stainless steel housing
- swivel bearing with double ball race
- ball bearings of stainless steel
- sealing ring
- also available with bolt hole LC (10,2 mm)
Areas of application
- industrial kitchen equipment
- bakery oven units
- catering equipment
- food processing industry
- food transport equipment
- laundry carts
- pharmaceutical industry
- serving trolleys
- waste disposal systems
398q 29K150v K2351ZA (PRIMACY)
Swivel castor with central total brake 100 mm - 200 mm, 100 kg - 150 kg
Technical data
| Diameter | 150 mm |
| Tread width | 32 mm |
| Height | 188 mm |
| Offset | 42 mm |
| Load capacity | 150 kg |
| Weight | 1192 g |
Wheel
- thermoplastic polyurethane tyre (TPU) iron grey RAL 7011, Shore A 95 plastic wheel centre and plastic thread guard, silver grey RAL 7001 precision ball bearing
Technical description
- die-cast aluminium load-bearing housing
- highly polished plastic cover
- precision ball bearings in the fork head
- suitable for cleaning in disinfection cabins
- smooth selection function
- integrated selection mechanism with total locking brake "q"
- and direction locking brake "r"
- permanently grease filled in the switch mechanism
- also available with electrically conductive wheel
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
398q 29K150v K985NP (PRIMACY)
Swivel castor with central total brake 100 mm - 200 mm, 100 kg - 150 kg
Technical data
| Diameter | 150 mm |
| Tread width | 32 mm |
| Height | 188 mm |
| Offset | 42 mm |
| Load capacity | 150 kg |
| Weight | 1204 g |
Wheel
- thermoplastic polyurethane tyre (TPU) iron grey RAL 7011, Shore A 95 plastic wheel centre and plastic thread guard, silver grey RAL 7001 precision ball bearing
Technical description
- die-cast aluminium load-bearing housing
- highly polished plastic cover
- precision ball bearings in the fork head
- suitable for cleaning in disinfection cabins
- smooth selection function
- integrated selection mechanism with total locking brake "q"
- and direction locking brake "r"
- permanently grease filled in the switch mechanism
- also available with electrically conductive wheel
Areas of application
- care beds
- hospital beds
- intensive care beds
- medical equipment
- op beds
- op tables
