JCCN 0803 6102
Swivel castor 80 mm - 140 mm, 200 kg - 500 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 36 mm |
| Height | 105 mm |
| Offset | 30 mm |
| Top plate dimensions | 120 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 95 x 60 mm |
| Load capacity | 200 kg |
| Weight | 2.5 kg |
Wheel
- Cast iron wheel with two deep groove ball bearings
Technical description
- Swivel fork of ductile cast iron GGG 40
- Swivelhead with sealed precision ball bearing
- and a grease nippel
JCCV 0803 6101
Swivel castor 80 mm - 140 mm, 180 kg - 500 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 36 mm |
| Height | 105 mm |
| Offset | 30 mm |
| Top plate dimensions | 120 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 95 x 60 mm |
| Load capacity | 180 kg |
| Weight | 2.3 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
Technical description
- Swivel fork of ductile cast iron GGG 40
- Swivelhead with sealed precision ball bearing
- and a grease nippel
JCTB 0803 6101
Swivel castor 80 mm - 140 mm, 85 kg - 300 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 30 mm |
| Height | 105 mm |
| Offset | 30 mm |
| Top plate dimensions | 120 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 95 x 60 mm |
| Load capacity | 85 kg |
| Weight | 2.1 kg |
Wheel
- Glass fibre reinforced polyamide hub, with fully elastic black rubber tyre
- (Shore A 65) and two deep groove ball bearings
Technical description
- Swivel fork of ductile cast iron GGG 40
- Swivelhead with sealed precision ball bearing
- and a grease nippel
JDPE 0501 1001
Swivel castor 50 mm - 125 mm, 40 kg - 120 kg
Technical data
| Diameter | 50 mm |
| Wheel width | 20 mm |
| Hub length | 24 mm |
| Height | 70 mm |
| Offset | 24 mm |
| Top plate dimensions | 60 x 60 mm |
| Top plate hole diameter | 6.3 mm |
| Dist. between holes | 48/38 x 48/38 mm |
| Brake swivel radius | 75 mm |
| Load capacity | 40 kg |
| Weight | 0.18 kg |
Wheel
- Polypropyleene wheel with a grey rubber tyre
- (Shore A 85) with zincplated threadguards
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball race way
- and sealring
JDPE 0505 1001
Swivel castor 50 mm - 125 mm, 40 kg - 120 kg
Technical data
| Diameter | 50 mm |
| Wheel width | 20 mm |
| Hub length | 24 mm |
| Height | 68 mm |
| Offset | 24 mm |
| Top plate hole diameter | 10.5 mm |
| Brake swivel radius | 75 mm |
| Load capacity | 40 kg |
| Weight | 0.14 kg |
Wheel
- Polypropyleene wheel with a grey rubber tyre
- (Shore A 85) with zincplated threadguards
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball race way
- and sealring
JDPU 0501 1000 TWIN
Swivel castor 50 mm, 100 kg
Technical data
| Diameter | 50 mm |
| Wheel width | 18 x 2 mm |
| Hub length | 40 mm |
| Height | 71 mm |
| Offset | 32 mm |
| Top plate dimensions | 60 x 60 mm |
| Top plate hole diameter | 6.3 mm |
| Dist. between holes | 48/38 x 48/38 mm |
| Brake swivel radius | 83 mm |
| Load capacity | 100 kg |
| Weight | 0.25 kg |
Wheel
- Double polypropylene wheel with grey polyurethane tyre
- (Shore D 70) and plain bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball race way
- and sealring
JDPU 0505 1000 TWIN
Swivel castor 50 mm, 100 kg
Technical data
| Diameter | 50 mm |
| Wheel width | 18 x 2 mm |
| Hub length | 40 mm |
| Height | 71 mm |
| Offset | 32 mm |
| Bolt hole diameter | 10.5 mm |
| Brake swivel radius | 83 mm |
| Load capacity | 100 kg |
| Weight | 0.21 kg |
Wheel
- Double polypropylene wheel with grey polyurethane tyre
- (Shore D 70) and plain bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball race way
- and sealring
JFCN 1003 6100
Swivel castor 100 mm - 250 mm, 800 kg - 1240 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Height | 152 mm |
| Offset | 52 mm |
| Top plate dimensions | 150 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 800 kg |
| Weight | 2.2 kg |
Wheel
- Cast iron wheel with two deep groove ball bearings
Technical description
- Heavy duty welded steel swivel fork. Swivel bearing with hardened race way, grease nippel and sealring.
- To order a four-station directional lock see article number 2304-0612. Only for Diameter 125 to 250 mm.
JFCV 1003 6100
Swivel castor 100 mm - 300 mm, 340 kg - 1500 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 38 mm |
| Hub length | 57 mm |
| Height | 152 mm |
| Offset | 52 mm |
| Top plate dimensions | 150 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 340 kg |
| Weight | 4.25 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
Technical description
- Heavy duty welded steel swivel fork. Swivel bearing with hardened race way, grease nippel and sealring.
- To order a four-station directional lock see article number 2304-0612. Only for Diameter 125 to 250 mm.
JFPN 1003 6100
Swivel castor 100 mm - 250 mm, 1000 kg - 1500 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 50 mm |
| Hub length | 62 mm |
| Height | 152 mm |
| Offset | 52 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 150 x 110 mm |
| Top plate hole diameter | 10.5 mm |
| Dist. between holes | 105 x 75,80 mm |
| Load capacity | 1000 kg |
| Weight | 2.1 kg |
Wheel
- Polyamide wheel with two deep groove ball bearings
Technical description
- Heavy duty welded steel swivel fork. Swivel bearing with hardened race way, grease nippel and sealring.
- To order a four-station directional lock see article number 2304-0612. Only for Diameter 125 to 250 mm.
