HAX 151052 P

HAX 151052 P

Technical data

Diameter 15 mm
Wheel axle diameter 10 mm
Weight 0.3 kg
Reach compliant Rohs compliant

Technical description

  • Hollow shaft out of stainless steel
ISO-210SUTM

Swivel castor 250 mm - 300 mm, 10000 kg - 12000 kg

Technical data

Diameter 250 mm
Wheel width 75 mm
Hub length 92 mm
Height 400 mm
Load capacity 10000 kg
Reach compliant Rohs compliant

Wheel

  • Heavy duty polyurethane wheel with a cast iron centre and two taper roller bearings

Technical description

  • Container Towcastor Kit: consists of two welded steel heavy duty swivel and fixed castors, the swivel forks are equipped with two tapered roller bearings and a grease nipple. Four locking screws, a lifting handle and a ratchet spanner are also included.
JA8SUB

JA8SUB

Technical data

Diameter 200 mm
Wheel width 51 mm
Height 266/342 mm
Offset 57 mm
Top plate dimensions 152x106 mm
Top plate hole diameter 12 mm
Dist. between holes 114,3x63,5 mm
Load capacity 1045 kg

Swivel castor 125 mm - 250 mm, 220 kg - 550 kg

Technical data

Diameter 125 mm
Wheel width 50 mm
Hub length 62 mm
Height 160 mm
Offset 50 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 220 kg
Weight 3.8 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel
  • with wheel brake. Swivelhead with sealed precision
  • ball bearings and a grease nippel

Swivel castor 125 mm - 250 mm, 220 kg - 550 kg

Technical data

Diameter 125 mm
Wheel width 50 mm
Hub length 62 mm
Height 160 mm
Offset 50 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 220 kg
Weight 3.8 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel
  • with wheel brake. Swivelhead with sealed precision
  • ball bearings and a grease nippel
JBAU 1253 6440

Swivel castor 125 mm - 160 mm, 450 kg - 600 kg

Technical data

Diameter 125 mm
Wheel width 50 mm
Hub length 62 mm
Height 160 mm
Offset 50 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 450 kg
Weight 3.4 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision
  • ball bearings and a grease nippel
JBAU 1253 6440/B

Swivel castor with wheel locking brake 125 mm - 160 mm, 450 kg - 600 kg

Technical data

Diameter 125 mm
Wheel width 50 mm
Hub length 62 mm
Height 160 mm
Offset 50 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 450 kg
Weight 3.7 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel
  • with wheel brake. Swivelhead with sealed precision
  • ball bearings and a grease nippel

Swivel castor 100 mm - 250 mm, 200 kg - 1000 kg

Technical data

Diameter 200 mm
Wheel width 50 mm
Hub length 62 mm
Height 235 mm
Offset 60 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 800 kg
Weight 4 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision
  • ball bearings and a grease nippel

Swivel castor 80 mm - 250 mm, 250 kg - 1000 kg

Technical data

Diameter 125 mm
Wheel width 50 mm
Hub length 64 mm
Height 160 mm
Offset 50 mm
Wheel axle diameter 20 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 1000 kg
Weight 5 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with two deep groove ball bearings

Technical description

  • Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel

Swivel castor with wheel locking brake 80 mm - 250 mm, 250 kg - 1000 kg

Technical data

Diameter 125 mm
Wheel width 50 mm
Hub length 64 mm
Height 160 mm
Offset 50 mm
Wheel axle diameter 20 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 1000 kg
Weight 5.3 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with two deep groove ball bearings

Technical description

  • Swivel fork of deep drawn zinc-coated steel
  • with wheel brake. Swivelhead with sealed precision
  • ball bearings and a grease nippel
