I61AZ-QM1K125 (Veloris)
Swivel castor 125 mm - 200 mm, 110 kg - 225 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 30 mm |
| Height | 156 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12,5 mm |
| Load capacity | 110 kg |
Wheel
- dark grey polypropylene hub
- ECOFORMA tread made of thermoplastic
- elastomer in light grey color with a hardness of 70 ± 5 Shore A
- single ball
- bearing
- *On request: antistatic version available.
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61AZ-UL2K080 (Veloris)
Swivel castor 80 mm - 125 mm, 150 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Height | 105 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,5 mm |
| Load capacity | 150 kg |
Wheel
- white nylon hub
- polyurethane TPU wheel tread in red color with a
- hardness of 95 ± 5 Shore A
- Ø80-125 mm single ball bearing
- Ø160-200 mm
- double ball bearing
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61AZ-XM9T100-C04 (Veloris)
Swivel castor 100 mm, 150 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Height | 128 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,5 mm |
| Load capacity | 150 kg |
Wheel
- die-cast aluminium hub
- wheel tread made of cast polyurethane in
- honey-brown color
- with a hardness of 95 +/- 5 Shore A
- double ball bearing
- *On request: antistatic version or soft tread 75 +/- 5 Shore A available.
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61TZ-BM7T100 (Veloris)
Swivel castor with total brake mounted behind 100 mm - 125 mm, 150 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Height | 128 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,5 mm |
| Brake swivel radius | 124 mm |
| Load capacity | 150 kg |
Wheel
- die-cast aluminium hub
- wheel tread made of natural rubber in black
- color
- with a hardness of 67 +/- 5 Shore A
- double ball bearing
- *On request: antistatic version or grey tread available.
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61TZ-NL3K080 (Veloris)
Swivel castor with total brake mounted behind 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Height | 105 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,5 mm |
| Brake swivel radius | 123 mm |
| Load capacity | 150 kg |
Wheel
- injection-molded PA6 nylon in white color
- with a hardness of 75 ± 5
- Shore D
- Ø80-125 mm single ball bearing
- Ø160-200 mm double ball bearing
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61TZ-PL1K080 (Veloris)
Swivel castor with total brake mounted behind 80 mm - 200 mm, 120 kg - 280 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Height | 105 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,5 mm |
| Brake swivel radius | 123 mm |
| Load capacity | 120 kg |
Wheel
- dark grey polypropylene hub
- PERFORMA® tread made of
- thermoplastic elastomer in grey color with a hardness of 65 ± 5 Shore A
- Ø80-125
- mm single ball bearing
- Ø160-200 mm double ball bearing
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61TZ-QM1K125 (Veloris)
Swivel castor with total brake mounted behind 125 mm - 200 mm, 110 kg - 225 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 30 mm |
| Height | 156 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12,5 mm |
| Load capacity | 110 kg |
Wheel
- dark grey polypropylene hub
- ECOFORMA tread made of thermoplastic
- elastomer in light grey color with a hardness of 70 ± 5 Shore A
- single ball
- bearing
- *On request: antistatic version available.
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61TZ-UL2K080 (Veloris)
Swivel castor with total brake mounted behind 80 mm - 125 mm, 150 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Height | 105 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,5 mm |
| Brake swivel radius | 123 mm |
| Load capacity | 150 kg |
Wheel
- white nylon hub
- polyurethane TPU wheel tread in red color with a
- hardness of 95 ± 5 Shore A
- Ø80-125 mm single ball bearing
- Ø160-200 mm
- double ball bearing
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I61TZ-XM9T100-C04 (Veloris)
Swivel castor with total brake mounted behind 100 mm, 150 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Height | 128 mm |
| Offset | 34 mm |
| Bolt hole diameter | 12,5 mm |
| Brake swivel radius | 124 mm |
| Load capacity | 150 kg |
Wheel
- die-cast aluminium hub
- wheel tread made of cast polyurethane in
- honey-brown color
- with a hardness of 95 +/- 5 Shore A
- double ball bearing
- *On request: antistatic version or soft tread 75 +/- 5 Shore A available.
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
I62AZ-BM7T100 (Veloris)
Swivel castor 100 mm - 200 mm, 150 kg - 400 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Height | 128 mm |
| Offset | 34 mm |
| Top plate dimensions | 104x85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80x60 mm |
| Load capacity | 150 kg |
Wheel
- die-cast aluminium hub
- wheel tread made of natural rubber in black
- color
- with a hardness of 67 +/- 5 Shore A
- double ball bearing
- *On request: antistatic version or grey tread available.
Technical description
- pressed components made of carbon steel
- protected with an additional
- electro-galvanized zinc coating
- fork headwork with a double ball race bearing
