BPSM 0801 2100
Swivel castor with total brake mounted behind 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Pressed sheetsteel wheel with black rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way and sealring (excluded the bolt hole fixing plate) with a total lock brake
BPSM 0801 2101
Swivel castor with total brake mounted behind 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 1 kg |
Wheel
- Pressed sheetsteel wheel with black rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way and sealring (excluded the bolt hole fixing plate) with a total lock brake
BPSM 0805 2000
Swivel castor with total brake mounted behind 80 mm - 200 mm, 50 kg - 160 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 103 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 0.8 kg |
Wheel
- Pressed sheetsteel wheel with black rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way and sealring (excluded the bolt hole fixing plate) with a total lock brake
BPSM 0805 2001
Swivel castor with total brake mounted behind 80 mm - 125 mm, 50 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 103 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Pressed sheetsteel wheel with black rubber tyre
- (Shore A 85) and roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way and sealring (excluded the bolt hole fixing plate) with a total lock brake
BTAB 1002 6150
Swivel castor with total brake mounted behind 100 mm - 250 mm, 180 kg - 450 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Hub length | 50 mm |
| Height | 130 mm |
| Offset | 40 mm |
| Top plate dimensions | 105 x 86 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80/77 x 60 mm |
| Brake swivel radius | 134 mm |
| Load capacity | 180 kg |
| Weight | 1.281 kg |
Wheel
- Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
BTAB 1005 6150
Swivel castor with total brake mounted behind 100 mm - 125 mm, 180 kg - 200 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Hub length | 50 mm |
| Height | 125 mm |
| Offset | 40 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 134 mm |
| Load capacity | 180 kg |
| Weight | 1.45 kg |
Wheel
- Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
BTAU 1002 6150
Swivel castor with total brake mounted behind 100 mm - 250 mm, 200 kg - 500 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Hub length | 50 mm |
| Height | 130 mm |
| Offset | 40 mm |
| Top plate dimensions | 105 x 86 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80/77 x 60 mm |
| Brake swivel radius | 134 mm |
| Load capacity | 200 kg |
| Weight | 1.5 kg |
Wheel
- Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
BTAU 1005 6150
Swivel castor with total brake mounted behind 100 mm - 125 mm, 200 kg - 250 kg
Technical data
| Diameter | 100 mm |
| Height | 125 mm |
| Offset | 40 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 134 mm |
| Load capacity | 200 kg |
| Weight | 1.35 kg |
Wheel
- Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
BTCN 2503 6443
Swivel castor with total brake mounted in front 250 mm, 500 kg
Technical data
| Diameter | 250 mm |
| Hub length | 64 mm |
| Height | 290 mm |
| Offset | 53 mm |
| Wheel axle diameter | 20 mm |
| Threaded stem size | 50 mm |
| Top plate dimensions | 135 x 110 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 80/75 mm |
| Load capacity | 500 kg |
| Weight | 7.2 kg |
Wheel
- Cast iron wheel with two deep groove ball bearings
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
BTCO 1002 5100
Swivel castor with total brake mounted behind 100 mm - 125 mm, 200 kg - 250 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 37 mm |
| Hub length | 48 mm |
| Height | 130 mm |
| Offset | 40 mm |
| Wheel axle diameter | 10 mm |
| Top plate dimensions | 105 x 86 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80/77 x 60 mm |
| Brake swivel radius | 134 mm |
| Load capacity | 200 kg |
| Weight | 1.1 kg |
Wheel
- Composite wheel polypropylene with red noise-reducing
- thermoplastic rubber infill with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
