WHCU 0802 62012
Wheel 80 mm - 500 mm, 250 kg - 4500 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 36 mm |
| Hub length | 36 mm |
| Wheel axle diameter | 15 mm |
| Load capacity | 250 kg |
Wheel
- Cast iron wheel with bonded-on polyurethane tyre (Shore A 92) with two taper roller bearings
WHCV 0803 6151
Wheel 80 mm - 100 mm, 210 kg - 350 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 45 mm |
| Wheel axle diameter | 15 mm |
| Load capacity | 210 kg |
| Weight | 0.6 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
WHCV 1253 6443
Wheel 125 mm - 250 mm, 500 kg - 1100 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Wheel axle diameter | 20 mm |
| Load capacity | 500 kg |
| Weight | 1.7 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
WHCV 1253 6553
Wheel 125 mm - 250 mm, 500 kg - 1100 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Wheel axle diameter | 25 mm |
| Load capacity | 500 kg |
| Weight | 1.7 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
WHCV 1253 6553/N=60
Wheel 125 mm - 250 mm, 500 kg - 1100 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 60 mm |
| Wheel axle diameter | 25 mm |
| Load capacity | 500 kg |
| Weight | 1.7 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
WHCV 3103 6662
Wheel 310 mm, 1500 kg
Technical data
| Diameter | 310 mm |
| Wheel width | 60 mm |
| Hub length | 78 mm |
| Wheel axle diameter | 30 mm |
| Load capacity | 1500 kg |
| Weight | 9.5 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
WHCV 3503 6662
Wheel 350 mm - 400 mm, 2000 kg - 2400 kg
Technical data
| Diameter | 350 mm |
| Wheel width | 70 mm |
| Hub length | 78 mm |
| Wheel axle diameter | 30 mm |
| Load capacity | 2000 kg |
| Weight | 14.5 kg |
Wheel
- Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings
WHHN 0702 6152
Wheel 70 mm - 100 mm, 160 kg - 250 kg
Technical data
| Diameter | 70 mm |
| Wheel width | 40 mm |
| Hub length | 45 mm |
| Wheel axle diameter | 8 mm |
| Load capacity | 160 kg |
| Weight | 0.25 kg |
Wheel
- Varmo a high wear resistant synthetic material High resistance to moisture and water Sound reducing properties Temperature resistance -40°C to + 300 °C with two deep groove ball bearings
WHHN 1002 6152/HN
Wheel 100 mm, 240 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Hub length | 45 mm |
| Wheel axle diameter | 8 mm |
| Load capacity | 240 kg |
| Weight | 0.4 kg |
Wheel
- Varmo a high wear resistant synthetic material High resistance to moisture and water Sound reducing properties and grease nipple Temperature resistance -40 °C to + 300 °C with two deep groove ball bearings
WHHS 0503 6030
Wheel 50 mm, 500 kg
Technical data
| Diameter | 50 mm |
| Wheel width | 30 mm |
| Hub length | 40 mm |
| Wheel axle diameter | 15 mm |
| Load capacity | 500 kg |
Wheel
- Single flanged wheels in special hardened steel, with two ball bearings, hardness from 180 to 230 HB, high static and dynamic load capacity and a high abrasion resistance.
