JXPN 1607 1000
Swivel castor 160 mm - 200 mm, 250 kg
Technical data
| Diameter | 160 mm |
| Hub length | 60 mm |
| Height | 195 mm |
| Offset | 53 mm |
| Wheel axle diameter | 20 mm |
| Threaded stem size | 50 mm |
| Load capacity | 250 kg |
| Weight | 1.5 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPP 0801 1100
Swivel castor 80 mm - 125 mm, 150 kg - 180 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 150 kg |
| Weight | 0.7 kg |
Wheel
- White Polypropyleene wheel
- with a plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPP 0805 1000
Swivel castor 80 mm - 125 mm, 150 kg - 180 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.5 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 150 kg |
| Weight | 0.6 kg |
Wheel
- White Polypropyleene wheel
- with a plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPR 0801 5100
Swivel castor 80 mm, 120 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 34 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 120 kg |
| Weight | 0.6 kg |
Wheel
- Dark grey Polypropyleene wheel with a blue elastic rubber tyre (Performa, Shore A 65-70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel with wheel brake.
- Swivelhead with sealed precision ball bearing, grease nippel
- and O-ring seal. In case of extreme conditions
- (like frequent jet cleaning) maintenance by relubrication
- is necessary
JXPR 0805 5000
Swivel castor 80 mm - 125 mm, 120 kg - 180 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 120 kg |
| Weight | 0.57 kg |
Wheel
- Dark grey Polypropyleene wheel with a blue elasticrubber tyre (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPR 1001 5100
Swivel castor 100 mm, 150 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 128 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 128 mm |
| Load capacity | 150 kg |
| Weight | 0.6 kg |
Wheel
- Dark grey Polypropyleene wheel with a blue elastic rubber tyre (Performa, Shore A 65-70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPR 1002 5000
Swivel castor 100 mm - 125 mm, 150 kg - 180 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 130 mm |
| Offset | 40 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 150 kg |
| Weight | 0.75 kg |
Wheel
- Dark grey Polypropyleene wheel with a blue elasticrubber tyre (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel. Swivelhead with
- sealed precision ball bearing, grease nippel and O-ring seal.
- In case of extreme conditions (like frequent jet cleaning) maintenance
- by relubrication is necessary
JXPR 1603 6443
Swivel castor 160 mm - 200 mm, 250 kg - 300 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Height | 195 mm |
| Offset | 55 mm |
| Top plate dimensions | 135 x 112 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 75,80 mm |
| Brake swivel radius | 145 mm |
| Load capacity | 250 kg |
| Weight | 2.03 kg |
Wheel
- Dark grey Polypropyleene wheel with blue elastic tyre
- (Performa, Shore A 65 - 70) with two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel. Swivelhead with
- sealed precision ball bearing, grease nippel and O-ring seal.
- In case of extreme conditions (like frequent jet cleaning) maintenance
- by relubrication is necessary
JXPR 1603 6443/B
Swivel castor 160 mm - 200 mm, 250 kg - 300 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Height | 195 mm |
| Offset | 55 mm |
| Top plate dimensions | 135 x 112 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 75,80 mm |
| Brake swivel radius | 145 mm |
| Load capacity | 250 kg |
| Weight | 2.2 kg |
Wheel
- Dark grey Polypropyleene wheel with blue elastic tyre
- (Performa, Shore A 65 - 70) with two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel with wheel brake.
- Swivelhead with sealed precision ball bearing, grease nippel
- and O-ring seal. In case of extreme conditions
- (like frequent jet cleaning) maintenance by relubrication
- is necessary
JXPT 1001 1000
Swivel castor 100 mm, 75 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 38 mm |
| Hub length | 40 mm |
| Height | 128 mm |
| Offset | 33 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 75 kg |
| Weight | 0.9 kg |
Wheel
- Plastic wheel with high temperature black rubber tyre
- (Shore A 62). Temperature resistance -40°C to + 300 °C
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
