JXPF 0805 7000
Swivel castor 80 mm - 125 mm, 120 kg - 180 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 120 kg |
| Weight | 0.58 kg |
Wheel
- Dark grey polypropylene wheel with grey rubber tyre
- (Performa, Shore A 65) with one stainless steel deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPF 1002 5000
Swivel castor 100 mm - 125 mm, 150 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 130 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 128 mm |
| Load capacity | 150 kg |
| Weight | 0.8 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel. Swivelhead with
- sealed precision ball bearing, grease nippel and O-ring seal.
- In case of extreme conditions (like frequent jet cleaning) maintenance
- by relubrication is necessary
JXPF 1005 5000
Swivel castor 100 mm - 125 mm, 150 kg - 180 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 128 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 128 mm |
| Load capacity | 150 kg |
| Weight | 0.7 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPF 1607 6443
Swivel castor 160 mm - 200 mm, 500 kg - 300 kg
Technical data
| Diameter | 160 mm |
| Hub length | 64 mm |
| Height | 195 mm |
| Offset | 53 mm |
| Wheel axle diameter | 20 mm |
| Threaded stem size | 50 mm |
| Load capacity | 500 kg |
| Weight | 2 kg |
Wheel
- Dark grey Polypropyleene wheel with grey elastic Performa tyre
- (65° - 70° Shore A) with two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPG 0801 1100
Swivel castor 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.7 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPG 0802 6123
Swivel castor 80 mm - 200 mm, 50 kg - 270 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 35 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 50 kg |
| Weight | 1 kg |
Wheel
- Polyamide wheel with grey rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel. Swivelhead with
- sealed precision ball bearing, grease nippel and O-ring seal.
- In case of extreme conditions (like frequent jet cleaning) maintenance
- by relubrication is necessary
JXPG 0802 6123/B
Swivel castor with wheel locking brake 80 mm - 200 mm, 50 kg - 270 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 35 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 50 kg |
| Weight | 1.2 kg |
Wheel
- Polyamide wheel with grey rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel with wheel brake.
- Swivelhead with sealed precision ball bearing, grease nippel
- and O-ring seal. In case of extreme conditions
- (like frequent jet cleaning) maintenance by relubrication
- is necessary
JXPG 0805 1000
Swivel castor 80 mm - 125 mm, 50 kg - 100 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.5 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.6 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPN 0801 1100
Swivel castor 80 mm - 200 mm, 200 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 200 kg |
| Weight | 0.7 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPN 0801 5100
Swivel castor 80 mm - 125 mm, 175 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 175 kg |
| Weight | 0.73 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
