JPSM 0805 2000
JPSM 0805 2000


Swivel castor 80 mm - 200 mm, 50 kg - 200 kg

Technical data

Diameter 80 mm
Wheel width 25 mm
Hub length 40 mm
Height 103 mm
Offset 38 mm
Wheel axle diameter 12 mm
Bolt hole diameter 12.3 mm
Brake swivel radius 108 mm
Load capacity 50 kg
Weight 0.7 kg
Reach compliant Rohs compliant

Wheel

  • Pressed sheetsteel wheel with black rubber tyre
  • (Shore A 85) and roller bearing

Technical description

  • Swivel fork of deep drawn zinc-coated steel,
  • swivel bearing with double ball race way
  • and sealring (excluded the bolt hole fixing plate)
JPSM 0805 2001
JPSM 0805 2001


Swivel castor 80 mm - 125 mm, 50 kg - 120 kg

Technical data

Diameter 80 mm
Wheel width 25 mm
Hub length 40 mm
Height 103 mm
Offset 38 mm
Wheel axle diameter 12 mm
Bolt hole diameter 12.3 mm
Brake swivel radius 108 mm
Load capacity 50 kg
Weight 0.8 kg
Reach compliant Rohs compliant

Wheel

  • Pressed sheetsteel wheel with black rubber tyre
  • (Shore A 85) and roller bearing

Technical description

  • Swivel fork of deep drawn zinc-coated steel,
  • swivel bearing with double ball race way
  • and sealring (excluded the bolt hole fixing plate)
JRCN 1003 2100
JRCN 1003 2100


Swivel castor 100 mm - 200 mm, 450 kg - 600 kg

Technical data

Diameter 100 mm
Wheel width 38 mm
Hub length 48 mm
Height 140 mm
Offset 33 mm
Wheel axle diameter 15 mm
Top plate dimensions 135 x 110 mm
Top plate hole diameter 10.5 mm
Dist. between holes 105 x 75,80 mm
Load capacity 450 kg
Weight 2.7 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with two deep groove ball bearings

Technical description

  • Swivel fork of deep drawn zinc-coated and yellow
  • passivated sheet steel swivel bearing with double
  • ball race way and a sealring
JRCU 1003 2100
JRCU 1003 2100


Swivel castor 100 mm - 200 mm, 295 kg - 600 kg

Technical data

Diameter 100 mm
Wheel width 45 mm
Hub length 48 mm
Height 140 mm
Offset 33 mm
Wheel axle diameter 15 mm
Top plate dimensions 135 x 110 mm
Top plate hole diameter 10.5 mm
Dist. between holes 105 x 75,80 mm
Load capacity 295 kg
Weight 2.6 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with bonded-on polyurethane tyre (Shore A 92) with two taper roller bearings

Technical description

  • Swivel fork of deep drawn zinc-coated and yellow
  • passivated sheet steel swivel bearing with double
  • ball race way and a sealring
JSAB 1002 6150
JSAB 1002 6150


Swivel castor 100 mm - 250 mm, 180 kg - 550 kg

Technical data

Diameter 100 mm
Wheel width 40 mm
Hub length 45 mm
Height 128 mm
Offset 40 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 120 mm
Load capacity 180 kg
Weight 1.3 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
JSAB 1002 6150/B
JSAB 1002 6150/B


Swivel castor with wheel locking brake 100 mm - 250 mm, 180 kg - 550 kg

Technical data

Diameter 100 mm
Wheel width 40 mm
Hub length 45 mm
Height 130 mm
Offset 40 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 120 mm
Load capacity 180 kg
Weight 1.5 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
  • ball bearing and a grease nippel
JSAU 1002 6150/B
JSAU 1002 6150/B


Swivel castor with wheel locking brake 100 mm - 200 mm, 200 kg - 650 kg

Technical data

Diameter 100 mm
Wheel width 40 mm
Hub length 45 mm
Height 130 mm
Offset 40 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9 mm
Dist. between holes 80 x 60 mm
Brake swivel radius 120 mm
Load capacity 200 kg
Weight 1.5 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
  • ball bearing and a grease nippel
JSAU 2503 6550
JSAU 2503 6550


Swivel castor 250 mm, 650 kg

Technical data

Diameter 250 mm
Wheel width 50 mm
Hub length 62 mm
Height 290 mm
Offset 65 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 650 kg
Weight 4.3 kg
Reach compliant Rohs compliant

Technical description

  • Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
JSAU 2503 6550/B
JSAU 2503 6550/B


Swivel castor with wheel locking brake 250 mm, 650 kg

Technical data

Diameter 250 mm
Wheel width 50 mm
Hub length 62 mm
Height 290 mm
Offset 65 mm
Top plate dimensions 135 x 112 mm
Top plate hole diameter 11 mm
Dist. between holes 105 x 75,80 mm
Brake swivel radius 145 mm
Load capacity 650 kg
Weight 4.6 kg
Reach compliant Rohs compliant

Wheel

  • Aluminium wheels with bonded-on polyurethane tyre (Shore A 92) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
  • ball bearing and a grease nippel
JSFL 1002 6152
JSFL 1002 6152


Swivel castor 100 mm, 240 kg

Technical data

Diameter 100 mm
Wheel width 40 mm
Hub length 45 mm
Height 130 mm
Offset 40 mm
Wheel axle diameter 15 mm
Top plate dimensions 105 x 85 mm
Top plate hole diameter 9 mm
Dist. between holes 80 x 60 mm
Load capacity 240 kg
Weight 1.3 kg
Reach compliant Rohs compliant

Wheel

  • Phenolic wheel for light Industrial use two ball bearings with labyrinth seals and bushing operating temperatures from -40°C to +250°C

Technical description

  • Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
