JPPN 0805 1001
Swivel castor 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 150 kg |
| Weight | 0.7 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPN 0805 2000
Swivel castor 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 150 kg |
| Weight | 0.6 kg |
Wheel
- Polyamide wheel with roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPN 0805 2001
Swivel castor 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 150 kg |
| Weight | 0.7 kg |
Wheel
- Polyamide wheel with roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPN 0805 5000
Swivel castor 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 8 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 150 kg |
| Weight | 0.7 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPP 0801 1100
Swivel castor 80 mm - 125 mm, 100 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 100 kg |
| Weight | 0.6 kg |
Wheel
- White Polypropyleene wheel
- with a plain bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPP 0801 1101
Swivel castor 80 mm - 125 mm, 100 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 100 kg |
| Weight | 0.7 kg |
Wheel
- White Polypropyleene wheel
- with a plain bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPP 0801 2100
Swivel castor 80 mm - 125 mm, 100 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 100 kg |
| Weight | 0.6 kg |
Wheel
- White Polypropyleene wheel
- with roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPP 0801 2101
Swivel castor 80 mm - 125 mm, 100 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 100 kg |
| Weight | 0.7 kg |
Wheel
- White Polypropyleene wheel
- with roller bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPP 0805 1000
Swivel castor 80 mm - 125 mm, 100 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 100 kg |
| Weight | 0.5 kg |
Wheel
- White Polypropyleene wheel
- with a plain bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
JPPP 0805 1001
Swivel castor 80 mm - 125 mm, 100 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.3 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 100 kg |
| Weight | 0.6 kg |
Wheel
- White Polypropyleene wheel
- with a plain bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel,
- swivel bearing with double ball race way
- and sealring (excluded the bolt hole fixing plate)
