316a 00G030z ZLB
Swivel castor 30 mm - 38 mm, 15 kg - 20 kg
Technical data
| Diameter | 30 mm |
| Tread width | 18 mm |
| Height | 46 mm |
| Offset | 15,5 mm |
| Bolt hole diameter | 8,2 mm |
| Load capacity | 15 kg |
| Weight | 78 g |
Wheel
- polypropylene black
- plain bearing
Technical description
- steel sheet housing
- single-row ball race in fork head
- zinc passivated
Areas of application
- audio furniture
- containers for hydroculture
- display stands
- greeting card dispensers
- mobile shelves
- small furniture
- shop fittings
- upholstered furniture
32C080bZ
Wheel 80 mm - 200 mm, 80 kg - 120 kg
Technical data
| Diameter | 80 mm |
| Tread width | 30 mm |
| Hub length | 37 mm |
| Wheel axle diameter | 8 mm |
| Load capacity | 80 kg |
| Weight | 291 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
32C100aZ
Wheel 75 mm - 200 mm, 50 kg - 120 kg
Technical data
| Diameter | 100 mm |
| Tread width | 32 mm |
| Hub length | 37 mm |
| Wheel axle diameter | 8 mm |
| Load capacity | 80 kg |
Wheel
- solid rubber tyre black (Shore A 80)
- electrically conductive
- free of contact discoloration
- metal thread guard
- sheet steel metal rim zinc passivated
- flange bearing
32C125wZ
Wheel 125 mm - 200 mm, 100 kg - 120 kg
Technical data
| Diameter | 125 mm |
| Tread width | 32 mm |
| Hub length | 37 mm |
| Wheel axle diameter | 8 mm |
| Load capacity | 100 kg |
Wheel
- 2-components-tyre blue-grey
- tread Shore A 60, tyre core Shore A 85
- sheet steel metal rim and thread guard zinc-passivated
- flange bearing
33C050bZ
Wheel 50 mm - 75 mm, 40 kg - 50 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Hub length | 22,5 mm |
| Wheel axle diameter | 6 mm |
| Load capacity | 40 kg |
| Weight | 70 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
33G050b-06
Wheel 50 mm - 100 mm, 40 kg - 65 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Hub length | 21,5 mm |
| Wheel axle diameter | 6 mm |
| Load capacity | 40 kg |
| Weight | 40 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- plain bearing
340a 29G050r ZLC-5
On request
Swivel castor 50 mm - 125 mm, 40 kg - 120 kg
Technical data
| Diameter | 50 mm |
| Tread width | 20 mm |
| Height | 68 mm |
| Offset | 24 mm |
| Bolt hole diameter | 10,5 mm |
| Load capacity | 40 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
340a 29G050r ZPC-5
On request
Swivel castor 50 mm - 125 mm, 40 kg - 120 kg
Technical data
| Diameter | 50 mm |
| Tread width | 20 mm |
| Height | 69,5 mm |
| Offset | 24 mm |
| Top plate dimensions | 60X60 mm |
| Top plate hole diameter | 6,3 mm |
| Dist. between holes | 43x43 mm |
| Load capacity | 40 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
340a 33C050b ZGC
Swivel castor 50 mm - 75 mm, 40 kg - 50 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 70 mm |
| Offset | 24 mm |
| Threaded stem size | M10x25 mm |
| Load capacity | 40 kg |
| Weight | 229 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
340a 33C050b ZLC
Swivel castor 50 mm - 75 mm, 40 kg - 50 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 67 mm |
| Offset | 24 mm |
| Bolt hole diameter | 10,2 mm |
| Load capacity | 40 kg |
| Weight | 198 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
