33C075bZ-08
Wheel 75 mm, 50 kg
Technical data
| Diameter | 75 mm |
| Tread width | 23 mm |
| Hub length | 28 mm |
| Wheel axle diameter | 8 mm |
| Load capacity | 50 kg |
| Weight | 108 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
33G050b-06
Wheel 50 mm - 100 mm, 40 kg - 65 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Hub length | 21,5 mm |
| Wheel axle diameter | 6 mm |
| Load capacity | 40 kg |
| Weight | 40 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- plain bearing
- Attention: wheel in Ø 50 mm riveted!
340a 29G050r ZLC-5
On request
Swivel castor 50 mm - 125 mm, 40 kg - 120 kg
Technical data
| Diameter | 50 mm |
| Tread width | 20 mm |
| Height | 68 mm |
| Offset | 24 mm |
| Bolt hole diameter | 10,5 mm |
| Load capacity | 40 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
340a 29G050r ZPC-5
On request
Swivel castor 50 mm - 125 mm, 40 kg - 120 kg
Technical data
| Diameter | 50 mm |
| Tread width | 20 mm |
| Height | 69,5 mm |
| Offset | 24 mm |
| Top plate dimensions | 60X60 mm |
| Top plate hole diameter | 6,3 mm |
| Dist. between holes | 43x43 mm |
| Load capacity | 40 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
340a 33C050b ZGC
Swivel castor 50 mm - 75 mm, 40 kg - 50 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 70 mm |
| Offset | 24 mm |
| Threaded stem size | M10x25 mm |
| Load capacity | 40 kg |
| Weight | 229 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
- Attention: wheel in Ø 50 mm riveted!
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
340a 33C050b ZLC
Swivel castor 50 mm - 75 mm, 40 kg - 50 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 67 mm |
| Offset | 24 mm |
| Bolt hole diameter | 10,2 mm |
| Load capacity | 40 kg |
| Weight | 198 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
- Attention: wheel in Ø 50 mm riveted!
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
340a 33C050b ZPB
Swivel castor 50 mm - 75 mm, 40 kg - 50 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 70 mm |
| Offset | 24 mm |
| Top plate dimensions | 54x54 mm |
| Top plate hole diameter | 6,3 mm |
| Dist. between holes | 40x40 mm |
| Load capacity | 40 kg |
| Weight | 247 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
- Attention: wheel in Ø 50 mm riveted!
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
340a 33C050b ZR
Swivel castor 50 mm - 75 mm, 40 kg - 50 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 70 mm |
| Offset | 24 mm |
| Load capacity | 40 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
- Attention: wheel in Ø 50 mm riveted!
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
340a 33G050b ZGC
Swivel castor 50 mm - 100 mm, 40 kg - 60 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 70 mm |
| Offset | 24 mm |
| Threaded stem size | M10x25 mm |
| Load capacity | 40 kg |
| Weight | 202 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- plain bearing
- Attention: wheel in Ø 50 mm riveted!
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
340a 33G050b ZLC
Swivel castor 50 mm - 100 mm, 40 kg - 60 kg
Technical data
| Diameter | 50 mm |
| Tread width | 18 mm |
| Height | 67 mm |
| Offset | 24 mm |
| Bolt hole diameter | 10,2 mm |
| Load capacity | 40 kg |
| Weight | 177 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- plain bearing
- Attention: wheel in Ø 50 mm riveted!
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- bedside cabinets
- garment stands
- computer tables
- display stands
- dustbins
- file carts
- housekeeping carts
- infusion stands
- newspaper dispensers
- greeting card dispensers
- sales stands
- small furniture
- sport equipment
- brochure display stands
