NKSL-31CN-L12 (VIVAX)
Swivel castor 75 mm, 70 kg
Technical data
| Diameter | 75 mm |
| Wheel width | 30 mm |
| Height | 109 mm |
| Offset | 41,5 mm |
| Bolt hole diameter | 12 mm |
| Load capacity | 70 kg |
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
NKSL-31CN-P100 (VIVAX)
Swivel castor 75 mm, 70 kg
Technical data
| Diameter | 75 mm |
| Wheel width | 30 mm |
| Height | 115 mm |
| Offset | 41,5 mm |
| Top plate dimensions | 100x80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80x60/76x55 mm |
| Load capacity | 70 kg |
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
NKSL-31CN-P77 (VIVAX)
Swivel castor 75 mm, 70 kg
Technical data
| Diameter | 75 mm |
| Wheel width | 30 mm |
| Height | 115 mm |
| Offset | 41,5 mm |
| Top plate dimensions | 77x66 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 61x51/56x46 mm |
| Load capacity | 70 kg |
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
NKSL-31CN-P95 (VIVAX)
Swivel castor 75 mm, 70 kg
Technical data
| Diameter | 75 mm |
| Wheel width | 30 mm |
| Height | 115 mm |
| Offset | 41,5 mm |
| Top plate dimensions | 95x70 mm |
| Top plate hole diameter | 8,5 mm |
| Dist. between holes | 75x50/72x52 mm |
| Load capacity | 70 kg |
Areas of application
- diagnostic equipment
- electronic equipment
- food industry
- food transport equipment
- medical-technical equipment
- transport trolleys
PGE30403WH-MNT33(GG) (GENESIS)
On request
Swivel castor 75 mm - 100 mm, 50 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 25 mm |
| Height | 100 mm |
| Offset | 37 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 50 kg |
Wheel
- MonoTech wheel with non-marking soft tyre (TPE Shore A 65)
- Precision ball bearing
- Integrated thread guards protect wheels from entangling debris
- Excellent application options on any floor type
Technical description
- GENESIS castor series
- Plastic castor (polyamide)
- Sealed precision bearing in swivel head provide quiet, effortless mobility
- Strong protective body conceals components for easy cleaning
- On request available with further fittings (plate, threaded stem, etc.) and in different colours (grey & black)
Areas of application
- small furniture
- medical & diagnostic equipment
PGE30403WH-MNT33(GG)B (GENESIS)
On request
Swivel castor with total brake mounted behind 75 mm - 100 mm, 50 kg - 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 25 mm |
| Height | 100 mm |
| Offset | 37 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 50 kg |
Wheel
- MonoTech wheel with non-marking soft tyre (TPE Shore A 65)
- Precision ball bearing
- Integrated thread guards protect wheels from entangling debris
- Excellent application options on any floor type
Technical description
- GENESIS castor series
- Plastic castor (polyamide)
- Sealed precision bearing in swivel head provide quiet, effortless mobility
- Strong protective body conceals components for easy cleaning
- On request available with further fittings (plate, threaded stem, etc.) and in different colours (grey & black)
Areas of application
- small furniture
- medical & diagnostic equipment
