Stainless Steel Castors
In the age of high technology the latest hygiene regulations shape the climate in laboratories for biotechnology, medicine and food research. Cleanliness is an essential part of quality management. Stainless steel castors from RHOMBUS are dazzling with their outstanding properties for this kind of environment. Produced from high-quality pure steel and precisely manufactured, they bring sterilising and instrument cabinets and other mobile units safe and clean to their destination.
FXPC 0802 7000
Fixed castor 80 mm - 200 mm, 80 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 80 kg |
| Weight | 0.41 kg |
Wheel
- Dark grey Polypropyleene wheel with grey antistatic rubber tyre
- (Performa, Shore A 65 - 70) with one stainless steel deep groove ball bearing
Technical description
- Rigid fork of stainless steel
FXPF 0801 7000
Fixed castor 80 mm - 200 mm, 120 kg - 300 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 120 kg |
| Weight | 0.42 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Rigid fork of stainless steel
FXPF 0802 7000
Fixed castor 80 mm - 200 mm, 120 kg - 300 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 120 kg |
| Weight | 0.42 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Rigid fork of stainless steel
FXPF 1252 5000
Fixed castor 125 mm, 180 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 40 mm |
| Hub length | 45 mm |
| Height | 160 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 180 kg |
| Weight | 0.8 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Rigid fork of stainless steel
FXPG 0801 1000
Fixed castor 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.5 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Rigid fork of stainless steel
FXPG 0802 6123
Fixed castor 160 mm - 200 mm, 175 kg - 270 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 35 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 50 kg |
| Weight | 0.6 kg |
Wheel
- Polyamide wheel with grey rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Rigid fork of stainless steel
FXPG 1602 6443
Fixed castor 160 mm - 200 mm, 175 kg - 270 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 40 mm |
| Hub length | 64 mm |
| Height | 195 mm |
| Offset | 55 mm |
| Wheel axle diameter | 20 mm |
| Top plate dimensions | 135 x 112 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 75,80 mm |
| Brake swivel radius | 145 mm |
| Load capacity | 175 kg |
| Weight | 1.9 kg |
Wheel
- Polyamide wheel with grey rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Rigid fork of stainless steel
FXPN 0801 1000
Fixed castor 80 mm - 200 mm, 150 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 150 kg |
| Weight | 0.5 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Rigid fork of stainless steel
FXPN 0801 5000
Fixed castor 80 mm - 100 mm, 150 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 150 kg |
| Weight | 0.6 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Rigid fork of stainless steel
FXPN 0801 7000
Fixed castor 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Load capacity | 150 kg |
| Weight | 0.6 kg |
Wheel
- Polyamide wheel with one sealed stainless steel
- deep groove ball bearing
Technical description
- Rigid fork of stainless steel
