Stainless Steel Castors
In the age of high technology the latest hygiene regulations shape the climate in laboratories for biotechnology, medicine and food research. Cleanliness is an essential part of quality management. Stainless steel castors from RHOMBUS are dazzling with their outstanding properties for this kind of environment. Produced from high-quality pure steel and precisely manufactured, they bring sterilising and instrument cabinets and other mobile units safe and clean to their destination.
BXPG 0801 1100
Swivel castor with total brake mounted behind 80 mm - 200 mm, 50 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPG 0805 1000
Swivel castor with total brake mounted behind 80 mm - 125 mm, 50 kg - 100 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.5 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPN 0801 1100
Swivel castor with total brake mounted behind 80 mm - 200 mm, 150 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 150 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPN 0801 5100
Swivel castor with total brake mounted behind 80 mm - 125 mm, 150 kg - 180 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 108 mm |
| Load capacity | 150 kg |
| Weight | 0.7 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPN 0801 7100
Swivel castor with total brake mounted behind 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 150 kg |
| Weight | 1.1 kg |
Wheel
- Polyamide wheel with one sealed stainless steel
- deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPN 0805 1000
Swivel castor with total brake mounted behind 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.5 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 150 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPN 0805 7000
Swivel castor with total brake mounted behind 80 mm - 125 mm, 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 150 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with one sealed stainless steel
- deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPN 1005 5000
Swivel castor with total brake mounted behind 100 mm - 125 mm, 150 kg - 180 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 128 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 128 mm |
| Load capacity | 150 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPN 1607 1000
Swivel castor with total brake mounted behind 160 mm - 200 mm, 250 kg
Technical data
| Diameter | 160 mm |
| Hub length | 60 mm |
| Height | 195 mm |
| Offset | 53 mm |
| Wheel axle diameter | 20 mm |
| Threaded stem size | 50 mm |
| Load capacity | 250 kg |
| Weight | 2 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
BXPP 0801 1100
Swivel castor with total brake mounted behind 80 mm - 125 mm, 150 kg - 180 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 40 mm |
| Height | 105 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 150 kg |
| Weight | 0.9 kg |
Wheel
- White Polypropyleene wheel
- with a plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
