Wheels & Accessories
The composition of the tyre and the various types of wheel rims or hubs as well as various wheel bearings give the wheel many different properties. Because of this wheels have differing load capacities, resistance to rolling and operational qualities.
WKPN 1603 6553
Wheel 160 mm - 200 mm, 625 kg - 780 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 25 mm |
| Load capacity | 625 kg |
| Weight | 0.8 kg |
Wheel
- Polyamide wheel with two deep groove ball bearings
WKPU 1253 6443
Wheel 125 mm - 200 mm, 320 kg - 515 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 20 mm |
| Load capacity | 320 kg |
| Weight | 0.5 kg |
Wheel
- Polyamide wheel with polyurethane tyre
- (Shore A 96) with two deep groove ball bearings
WKPU 1253 6553
Wheel 125 mm - 200 mm, 320 kg - 515 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 25 mm |
| Load capacity | 320 kg |
| Weight | 0.5 kg |
Wheel
- Polyamide wheel with polyurethane tyre
- (Shore A 96) with two deep groove ball bearings
WKRB 1603 6443
Wheel 160 mm - 250 mm, 300 kg - 475 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 20 mm |
| Load capacity | 300 kg |
| Weight | 1.1 kg |
Wheel
- Glass fibre reinforced polyamide wheel with black rubber tyre
- (Shore A 65) with two deep groove ball bearings
WKRB 1603 6553
Wheel 160 mm - 250 mm, 300 kg - 475 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 25 mm |
| Load capacity | 300 kg |
| Weight | 1.1 kg |
Wheel
- Glass fibre reinforced polyamide wheel with black rubber tyre
- (Shore A 65) with two deep groove ball bearings
WKRG 1603 6443
Wheel 160 mm - 250 mm, 300 kg - 475 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 20 mm |
| Load capacity | 300 kg |
| Weight | 1.1 kg |
Wheel
- Glass fibre reinforced polyamide wheel with grey rubber tyre
- (Shore A 65) with two deep groove ball bearings
WKRG 1603 6553
Wheel 160 mm - 250 mm, 300 kg - 475 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 25 mm |
| Load capacity | 300 kg |
| Weight | 1.1 kg |
Wheel
- Glass fibre reinforced polyamide wheel with grey rubber tyre
- (Shore A 65) with two deep groove ball bearings
WKRN 1253 6443
Wheel 125 mm - 200 mm, 490 kg - 650 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 20 mm |
| Load capacity | 490 kg |
| Weight | 0.5 kg |
Wheel
- Glass fibre reinforced polyamide wheel
WKRN 1253 6553
Wheel 125 mm - 200 mm, 490 kg - 650 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 25 mm |
| Load capacity | 490 kg |
| Weight | 0.5 kg |
Wheel
- Glass fibre reinforced polyamide wheel
WKTB 1253 6443
Wheel 125 mm, 240 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 54 mm |
| Hub length | 71 mm |
| Wheel axle diameter | 20 mm |
| Load capacity | 240 kg |
| Weight | 0.9 kg |
Wheel
- Glass fibre reinforced polyamide hub, with fully elastic black rubber tyre
- (Shore A 65) and two deep groove ball bearings
