Apparatus Castors

Whether in the small neighbourhood bistro, the hotel or the large canteen, the demands on people and equipment have grown. So it is important that the work can be handled with ease, for satisfied guests and contented workers.

It is a good thing the solid and robust castors from RHOMBUS also play their part with ease, because cooking equipment, food dispensers and other appliances have been mounted on them for years. RHOMBUS serves them fresh from the factory.

341h 33G075b ZPC

Swivel castor with total brake mounted behind 75 mm - 100 mm, 50 kg - 60 kg

Technical data

Diameter 75 mm
Tread width 24 mm
Height 103 mm
Offset 37 mm
Top plate dimensions 60x60 mm
Top plate hole diameter 6,3 mm
Dist. between holes 47x47/37x37 mm
Load capacity 50 kg
Weight 415 g
Reach compliant Rohs compliant

Wheel

  • solid rubber tyre blue-grey (Shore A 80)
  • plastic wheel centre grey
  • plain bearing

Technical description

  • sheet steel metal housing
  • swivel bearing with double ball race
  • zinc passivated

Areas of application

  • bedside cabinets
  • garment stands
  • computer tables
  • display stands
  • dustbins
  • file carts
  • housekeeping carts
  • infusion stands
  • newspaper dispensers
  • greeting card dispensers
  • sales stands
  • small furniture
  • sport equipment
  • brochure display stands
341h 33G075b ZR

Swivel castor with total brake mounted behind 75 mm - 100 mm, 50 kg - 60 kg

Technical data

Diameter 75 mm
Tread width 24 mm
Height 103 mm
Offset 37 mm
Load capacity 50 kg
Reach compliant Rohs compliant

Wheel

  • solid rubber tyre blue-grey (Shore A 80)
  • plastic wheel centre grey
  • plain bearing

Technical description

  • sheet steel metal housing
  • swivel bearing with double ball race
  • zinc passivated

Areas of application

  • bedside cabinets
  • garment stands
  • computer tables
  • display stands
  • dustbins
  • file carts
  • housekeeping carts
  • infusion stands
  • newspaper dispensers
  • greeting card dispensers
  • sales stands
  • small furniture
  • sport equipment
  • brochure display stands

Fixed castor 50 mm - 125 mm, 40 kg - 120 kg

Technical data

Diameter 50 mm
Tread width 20 mm
Height 69,5 mm
Top plate dimensions 60X60 mm
Top plate hole diameter 6,3 mm
Dist. between holes 43x43 mm
Load capacity 40 kg

Wheel

  • thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
  • plastic wheel centre silver grey RAL7001
  • without thread guard
  • plain bearing
  • Contact discoloration on unsealed grounds possible!>>

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • bedside cabinets
  • garment stands
  • computer tables
  • display stands
  • dustbins
  • file carts
  • housekeeping carts
  • infusion stands
  • newspaper dispensers
  • greeting card dispensers
  • sales stands
  • small furniture
  • sport equipment
  • brochure display stands
345a 33C050b ZPB

Fixed castor 50 mm - 75 mm, 40 kg - 50 kg

Technical data

Diameter 50 mm
Tread width 18 mm
Height 70 mm
Top plate dimensions 54x54 mm
Top plate hole diameter 6,3 mm
Dist. between holes 40x40 mm
Load capacity 40 kg
Weight 173 g
Reach compliant Rohs compliant

Wheel

  • solid rubber tyre blue-grey (Shore A 80)
  • plastic wheel centre grey
  • metal thread guard zinc-passivated (from Ø 75 mm)
  • flange bearing

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • bedside cabinets
  • garment stands
  • computer tables
  • display stands
  • dustbins
  • file carts
  • housekeeping carts
  • infusion stands
  • newspaper dispensers
  • greeting card dispensers
  • sales stands
  • small furniture
  • sport equipment
  • brochure display stands

Fixed castor 50 mm - 100 mm, 40 kg - 60 kg

Technical data

Diameter 50 mm
Tread width 18 mm
Height 70 mm
Top plate dimensions 54x54 mm
Top plate hole diameter 6,3 mm
Dist. between holes 40x40 mm
Load capacity 40 kg
Weight 148 g
Reach compliant Rohs compliant

Wheel

  • solid rubber tyre blue-grey (Shore A 80)
  • plastic wheel centre grey
  • plain bearing

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • bedside cabinets
  • garment stands
  • computer tables
  • display stands
  • dustbins
  • file carts
  • housekeeping carts
  • infusion stands
  • newspaper dispensers
  • greeting card dispensers
  • sales stands
  • small furniture
  • sport equipment
  • brochure display stands
346a 30C100b ZPC

Fixed castor 100 mm, 65 kg

Technical data

Diameter 100 mm
Tread width 23 mm
Height 124 mm
Top plate dimensions 60x60 mm
Top plate hole diameter 6,3 mm
Dist. between holes 47x47/37x37 mm
Load capacity 65 kg
Weight 609 g
Reach compliant Rohs compliant

Wheel

  • solid rubber tyre blue-grey (Shore A 80)
  • sheet steel metal rim
  • thread guard zinc passivated
  • flange bearing

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • bedside cabinets
  • garment stands
  • computer tables
  • display stands
  • dustbins
  • file carts
  • housekeeping carts
  • infusion stands
  • newspaper dispensers
  • greeting card dispensers
  • sales stands
  • small furniture
  • sport equipment
  • brochure display stands
354a 29G100r ZPF

Fixed castor 100 mm - 125 mm, 100 kg

Technical data

Diameter 100 mm
Tread width 30 mm
Height 129,5 mm
Top plate dimensions 95x70 mm
Top plate hole diameter 9 mm
Dist. between holes 75x45/72x52 mm
Load capacity 100 kg
Reach compliant Rohs compliant

Wheel

  • thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
  • plastic wheel centre silver grey RAL7001
  • without thread guard
  • plain bearing
  • Contact discoloration on unsealed grounds possible!>>

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods

Fixed castor 100 mm - 150 mm, 100 kg - 120 kg

Technical data

Diameter 100 mm
Tread width 30 mm
Height 129,5 mm
Top plate dimensions 95x70 mm
Top plate hole diameter 9 mm
Dist. between holes 75x45/72x52 mm
Load capacity 100 kg
Reach compliant Rohs compliant

Wheel

  • thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
  • plastic wheel centre and thread guard silver grey RAL7001
  • precision ball bearing
  • Contact discoloration on unsealed grounds possible!>>

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods

Fixed castor 100 mm - 150 mm, 80 kg - 110 kg

Technical data

Diameter 100 mm
Tread width 32 mm
Height 129,5 mm
Top plate dimensions 95x70 mm
Top plate hole diameter 9 mm
Dist. between holes 75x45/72x52 mm
Load capacity 80 kg
Reach compliant Rohs compliant

Wheel

  • solid rubber tyre blue-grey (Shore A 80)
  • sheet steel metal rim zinc passivated
  • metal thread quard
  • flange bearing

Technical description

  • sheet steel metal housing
  • zinc passivated

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods
357a 29G100r Z522

Swivel castor 100 mm - 125 mm, 100 kg

Technical data

Diameter 100 mm
Tread width 30 mm
Height 132,5 mm
Offset 41,5 mm
Stem size 24x45 M8/19 mm
Load capacity 100 kg
Reach compliant Rohs compliant

Wheel

  • thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
  • plastic wheel centre silver grey RAL7001
  • without thread guard
  • plain bearing
  • Contact discoloration on unsealed grounds possible!>>

Technical description

  • sheet steel metal housing
  • swivel bearing with double ball race
  • zinc passivated
  • also available with plate PD (77x67 mm) and bolt hole LC (11 mm)

Areas of application

  • brochure display stands
  • care beds
  • cleaning equipment
  • computer area
  • display stands
  • dustbins
  • file carts
  • food transport equipment
  • housekeeping carts
  • industrial kitchens
  • laundry carts
  • medical equipment
  • newspaper dispensers
  • occasional carts
  • restaurant areas
  • sales stands
  • shop fittings
  • sport equipment
  • tripods
