Swivel castor, 100 mm, 250 kg
Part number: 403a 29K100y K00-2
Technical data
| Diameter | 100 mm |
| Tread width | 2x30 mm |
| Height | 123,5 mm |
| Offset | 30 mm |
| Stem size | 32 mm |
| Brake swivel radius | 95 mm |
| Load capacity | 250 kg |
Notes for attachment:
The castor is installed by using a hydraulic system to be ordered separately.
For more detailed information, please click here:
Cooperation partner: HAWE
Technical description
- Plunger lock castor series 403
- Plastic twin wheel castor
- Precision ball bearings in swivel section and wheel
Wheel
- TPU-wheels (Shore A 95)
- electrically conductive
Areas of application
- Medical equipment, for example OP-tables
