Apparatus Castors
Whether in the small neighbourhood bistro, the hotel or the large canteen, the demands on people and equipment have grown. So it is important that the work can be handled with ease, for satisfied guests and contented workers.
It is a good thing the solid and robust castors from RHOMBUS also play their part with ease, because cooking equipment, food dispensers and other appliances have been mounted on them for years. RHOMBUS serves them fresh from the factory.
357h 29K100r Z622-5
Swivel castor with total brake mounted behind 100 mm - 150 mm, 90 kg - 130 kg
Technical data
Diameter | 100 mm |
Tread width | 32 mm |
Height | 138,5 mm |
Offset | 43,5 mm |
Stem size | 28x44,5 mm |
Load capacity | 90 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,5 mm) andswivel castors with directional brake (357r)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 29K100r ZGD-5
Swivel castor with total brake mounted behind 100 mm - 150 mm, 90 kg - 130 kg
Technical data
Diameter | 100 mm |
Tread width | 32 mm |
Height | 135 mm |
Offset | 43,5 mm |
Threaded stem size | M12x30 mm |
Load capacity | 90 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,5 mm) andswivel castors with directional brake (357r)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 29K100r ZLD
Swivel castor with total brake mounted behind 100 mm - 150 mm, 100 kg - 120 kg
Technical data
Diameter | 100 mm |
Tread width | 30 mm |
Height | 129,5 mm |
Offset | 47,5 mm |
Bolt hole diameter | 13 mm |
Load capacity | 100 kg |
Weight | 755 g |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with plate PD (77x67 mm) and bolt hole LC (11 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 29K100r ZLD-5
Swivel castor with total brake mounted behind 100 mm - 150 mm, 90 kg - 130 kg
Technical data
Diameter | 100 mm |
Tread width | 32 mm |
Height | 135 mm |
Offset | 38 mm |
Bolt hole diameter | 12,5 mm |
Load capacity | 90 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,5 mm) andswivel castors with directional brake (357r)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 29K100r ZPF
Swivel castor with total brake mounted behind 100 mm - 150 mm, 100 kg - 120 kg
Technical data
Diameter | 100 mm |
Tread width | 30 mm |
Height | 129,5 mm |
Offset | 47,5 mm |
Top plate dimensions | 95x70 mm |
Top plate hole diameter | 9 mm |
Dist. between holes | 75x45/72x52 mm |
Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with plate PD (77x67 mm) and bolt hole LC (11 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 29K100r ZPH-5
Swivel castor with total brake mounted behind 100 mm - 150 mm, 90 kg - 130 kg
Technical data
Diameter | 100 mm |
Tread width | 32 mm |
Height | 135 mm |
Offset | 43,5 mm |
Top plate dimensions | 100x80 mm |
Top plate hole diameter | 9 mm |
Dist. between holes | 80x60 mm |
Load capacity | 90 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with bolt hole LC (10,5 mm) andswivel castors with directional brake (357r)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 29K100r ZR
Swivel castor with total brake mounted behind 100 mm - 150 mm, 100 kg - 120 kg
Technical data
Diameter | 100 mm |
Tread width | 30 mm |
Height | 132,5 mm |
Offset | 47,5 mm |
Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre and thread guard silver grey RAL7001
- precision ball bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with plate PD (77x67 mm) and bolt hole LC (11 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 32C100b Z522
Swivel castor with total brake mounted behind 100 mm - 150 mm, 80 kg - 110 kg
Technical data
Diameter | 100 mm |
Tread width | 32 mm |
Height | 132,5 mm |
Offset | 47,5 mm |
Stem size | 24x45 M8/19 mm |
Load capacity | 80 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with plate PD (77x67 mm) and bolt hole LC (11 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 32C100b ZLD
Swivel castor with total brake mounted behind 100 mm - 150 mm, 80 kg - 110 kg
Technical data
Diameter | 100 mm |
Tread width | 32 mm |
Height | 129,5 mm |
Offset | 47,5 mm |
Bolt hole diameter | 13 mm |
Load capacity | 80 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with plate PD (77x67 mm) and bolt hole LC (11 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
357h 32C100b ZPF
Swivel castor with total brake mounted behind 100 mm - 150 mm, 80 kg - 110 kg
Technical data
Diameter | 100 mm |
Tread width | 32 mm |
Height | 129,5 mm |
Offset | 47,5 mm |
Top plate dimensions | 95x70 mm |
Top plate hole diameter | 9 mm |
Dist. between holes | 75x45/72x52 mm |
Load capacity | 80 kg |
Weight | 1090 g |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- sheet steel metal rim zinc passivated
- metal thread quard
- flange bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
- also available with plate PD (77x67 mm) and bolt hole LC (11 mm)
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
